SeQual INTEGRA E-Z - Integra E-Z 5 L Specifications

Service Manual
Integra E-Z Oxygen Concentrators
Chart SeQual Technologies Inc. Page 31 of 34 P/N 2917
7. Integra E-Z 5L Specifications
Integra E-Z Model Number 6323A / 6323A-OM Technical Data
Flow Rate
0.5 to 5.0 LPM
Oxygen Concentration
1.0 to 5.0 LPM 91 ± 3% at sea level
Oxygen Concentration Indicator
Green Light = Normal Operation
Yellow Light Flashing = Below Normal Operation (85%*)
Red Light Flashing = Abnormal Operation (70%**)
Oxygen Outlet Pressure
Nominal 7.5 psig (51.7 kPa)
1
- Maximum 11.0 psig (75.8 kPa)
Electrical Power
220-240V~, 50Hz, 1.6A Nominal
Operating Temperature
50° F to 104° F (10° C to 40° C)
Sound Level
51.5 dBA Nominal
Dimensions (H x W x D)
26.5 in. (66 cm) H × 14.7in. (37 cm) W × 19.5 in. (50 cm) D
Audible Alarm Indicators
Power Interruption
Power Surge (simulated circuit breaker)
Compressor Malfunction
Excessive Internal Temperature
Outlet Pressure [35-36 psig (241.2-248.1 kPa) relief valve]
Abnormal Oxygen Flow Rate >±30% target flow
Low Therapeutic Oxygen Output** <70% oxygen
Back-up Alarm Power
9V Battery
Filters
Cabinet Air Inlet, Compressor Inlet and HEPA
Device Classification
IEC Class II, Type BF Applied Part, Continuous Operation
Transport/Storage Requirements
Temperature: -4° F (-20° C) to +140° F (+60° C)
Humidity: Up to 95% Non-Condensing
Back pressure Effect on
Flow Indicator
0 psig (0 kPa): 5.0 LPM
1 psig (7 kPa): 5.0 LPM Nominal
OSCI Operation*
Temperature: 50° F to 104° F (10° C to 40° C) Independent of
Atmospheric Pressure.
85±3% and 70±5% oxygen concentration measurement accuracy
*Where equipped. Subject to ±3% system concentration accuracy, and for backpressures up to 7kPa.
**Where equipped. Subject to ±5% system concentration accuracy, and for backpressures up to 7kPa.
1
Outlet pressure may decline to 5.0 psig (34.5 kPa) nominal at 10,000 ft altitude.
System performance may decline above 10,000 ft (3048m).
