CONNECTING A DPG
DPG CONNECTORS
0311385 Issue : April 1999
2-19
ANALOG PILOTS connector
Connector Type: 12-14N
PILOT Signal Name
A PILOT1-
B PILOT2-
C PILOT3-
D PILOT4-
E RETURN-PILOT-
F RETURN-SWEEP-
H AGND2
J AGND1
K RETURN-SWEEP+
L RETURN-PILOT+
M PILOT4+
N PILOT3+
P PILOT2+
R PILOT1+
COM 2 connector
Connector Type: DB9P
COM2 Signal Name
1 CD Not used
2 RX In
3 TX Out
4 DTR Not used
5 LGND
6 DSR Not used
7 RTS Out
8 CTS In
9 RI Not used
- -
