12
Step 3.5
Bag 15,16
Rear Assembly
P10
2.5x22mm
Step 3.6
Rear Assembly
G21
M4x16mm
2
1
3
4
5
1
2
18.6mm
17.6mm
Rear
Front
U14
12x21mm
