7
Step 2.1
Bag 02,U
Front Assembly
Y12
10.3x1.8mm
Step 2.2
Bag 03,G20
Front Assembly
G20
M4x12mm
2.0 Front Assembly
1
2
2
3
3
1
1
2
OW
OW
U14
12x21mm
