25
Step 8.1
Bag 31
Final Assembly
F13
3x12mm
G27
M5x12mm
Step 8.2
Bag 32
Final Assembly
E14
3x16mm
G19
M4x10mm
G20
M4x12mm
8.0 Final Assembly
1
2
2
1
2
3
3
G20
