Serpent 950 - Rear Assembly

11
Step 3.3
Bag 12,13
Rear Assembly
B13
3.5x13mm
E11
3x8mm
E18
4x8mm
G20
M4x12mm
Step 3.4
Bag 14
Rear Assembly
E11
3x8mm
NN4
3.2x9x0.1mm
3
1
4
6
7
10
8
9
11
12
1
4
4
2
5
2
13
1.3mm
49mm
1:1
H13
3x12mm
H19
4x10mm
H22
4x20mm
J16
4x4mm
4
3
Use the special tool to aid you in
placing the steel pivot ball into
the wishbone end point.
3
Note: The anti-roll bar must move freely in
order to operate correctly - never over tighten
the mounting screws.
