Length measured after assembling between the two black lines.
How to use
In every step you will see a selection of lines and numbers. The numbers represent the order in which the
step should be assembled. The lines and symbols are listed below each with their own explanation as to
their use.
Key
Description
To display the path of one element into another.
The parts within the lines should be assembled first.
The direction the item should be moved.
Shows where one element should be glued to another.
Shows where one part should be pressed / inserted into another.
Displays where two elements should be connected to each other.
The gap between two elements.
Displays where either CA glue / Graphite Grease / Thread Lock / or
Serpent’s Oneway lube should be applied (items not included).
myTSN.com
The manual that comes with your Serpent 950 is
very complete. However, as development is a
continuous process, up-to-date information about
the Serpent 950 is provided on our web portal:
myTSN.com, the state-of-the-art r/c technology
portal where Serpent racers from all over the world
meet and exchange their ideas and share useful
information about, and experiences with, their
Serpent cars.
All information about the Serpent 950 is grouped
around the product page on myTSN.com. This page
can be accessed directly by going to the Products
section and type Serpent 950 in the product search
box.
Here you will find the very latest information about
your Serpent 950: reports by Team racers and
other experts with the latest tips and tricks, FAQ,
forums, set-ups, image gallery, downloadable files,
and even streaming video about the Serpent 950
on how to further improve the car. The latest
version of the manual including team and racer
tips, as well as part lists and option lists will be
made available as both downloadable PDF-files and
viewable online under i-Manual in the Serpent 950
product page.
So make sure to visit myTSN and the Serpent 950
page. There is a world of up-to-date information
about your 950 waiting for you, and it is just a few
mouse clicks away… If not yet a member of
myTSN, we strongly suggest to sign up as a
member immediately so you can experience and
enjoy an even wider range of services from Serpent
and other myTSN partners.
www.myTSN.com/Serpent950
