Serpent 950 - Rear Assembly

10
Step 3.1
Bag 08,09
Rear Assembly
G20
M4x12mm
P10
2.5x22mm
Q14
3x16mm
R5
5mm
Step 3.2
Bag 10,11
Rear Assembly
B13
3.5x13mm
G20
M4x12mm
J16
4x4mm
P12
3x12mm
3.0 Rear Assembly
1
2
3
9
4
10
11
7
5
6
8
1
2
5
3
4
6
7
8
9
10
11
12
Roughen the metal plates with
sandpaper before gluing
U8
6x15mm
U14
12x21mm
U8
6x15mm
Q14
P9
P10
P9
2.5x20mm
