Step 2.5
Front Assembly
J16
4x4mm
R5
5mm
R7
7mm
Step 2.6
Bag 06
Front Assembly
H13
3x12mm
H19
4x10mm
J16
4x4mm
Step 2.7
Bag 07
Front Assembly
E13
3x12mm
H17
4x6mm
9
3
1
2
4
5
6
5
2
4
3
1
1
2
4
2
3
