19
Step 5.6
Radio Plate Mounting
Step 5.7
Radio Plate Mounting
H10
3x6mm
1
2
3
3
1
2
2
88.5mm
1:1
You can screw the hex head
graphite balls into place from the
bottom of the chassis.
