Step 6.3
Gearbox Assembly
G10
M3x6mm
U6
6x13mm
V5
6x10mm
Step 6.4
Gearbox Assembly
P13
3x13.8mm
R5
5mm
1
2
2
3
1
2
3
4
5
OW
