Serstech ARX - Calibration Cap; USB Cable; Barcode Reader

15
WARNING: Keep the sample pressed
against the adaptor throughout the analy-
sis process.
3.3
Calibration cap
The calibration cap contains a polystyrene
target and is used for the calibration control
of the instrument. It is also protecting the
optics inside the probe tip.
3.4
USB Cable
The supplied USB cable is the connection
cable between the Arx and a PC, used to
access ChemDash 2.0.
The USB cable is also used to connect the
optional USB charger to the instrument.
3.5
Barcode reader
For samples that contain a barcode the built-in barcode reader can be used to append this
information to the measurement. The barcode reader is located on the back side of the in-
strument and is run from the Advanced scan.
The barcode reader is located in the
upper left corner on the instrument`s
backside
