The LA10 is usually supplied from
the main battery. Please make
sure the correct connection: red cable to
battery plus, black cable to battery mi-
nus.
The outputs are short circuit and
overload protected. Light bulbs,
Servonaut-light sets or single leds (with
serial resistor) can be connected.
Extra1 and 2 are general purpose
switching outputs, but can be config-
ured to other functionality with Servo-
naut CARD, see chapter Settings.
These two inputs are connected
to the corresponding outputs of
the speed controller (e.g. Servonaut
S22, E22).
Set the IR-transmitter power to
25% if the IR-transmission is ac-
complished through the kingpin (Servo-
naut KBT, KBC, KBW).
Cornering lights and automatic
disabling of indicators need the
steering signal to be connected to the
LA10. To do so you can simply connect
the steering servo here and the steering
signal from the receiver next to it.
1
2
3
4
5
Depending on the desired func-
tionallity the inputs F1 to F3 are
connected to the receiver. See chapter
connection variants.
The optional Servo signals 5 and 6 are
transmitted to the trailer directly (only
with IR-transmission).
For the operation with a trailer an
IR-transmitter diode (Servonaut
AIR-Diode/new) needs to be connected
here.
Both supply voltage outputs are
internally fused up to 500mA
each. The small lamps and LEDs can be
directly connected to the positive battery
pole. We recommend to use these se-
cured outputs for best protection. The
internal fuses are "self-healing".
6
7
8
