Servonaut LA10 User Manual

26
Connection Overview
Input break light
Input reversing light
Jumper IR Power
To steering servo From receiver
Output
IR-Transmitter diode
“AIR-DIODE/NEU”
Wire to battery
1
2
2
3
4
5 6
7
8
High beam / Flasher
Fog rear light
Cornering light/fog light left
Cornering light/fog light right
see text
battery Plus
see text
Indicator right
Indicator left
Low beam
Parking light
