31
Input F3: Extra outputs, functions on
trailer
L/R - Short operation of the joystick
(from the middle position) or the switch
to the left or right activates Extra1 and 2
at the LA10 in case they are configured
as general purpose output (preset val-
ue).
L/R - Long operation to the left or right
activates the Extra function 3 or 4 on
AMO/AM10.
Extra 3 operates Servo 3 at the AMO
/AM10* full left / full right.
Extra 4 operates special function 6 at
the AMO and Extra 4 output on AM10*.
Tip: In case on one of the chan-
nels F1, F2 or F3 left and right
is swapped, e.g. pressing the
switch to the right but the left indicator is
activated, all you need to do is to “invert”
this channel in the radio settings. Refer
to manual of your radio.
… with multichannel
Radios that support multichannel with
Robbe or Graupner standard can con-
trol the lighting system using only one
channel of the receiver. Only one patch
cable from the receiver to F1 is required.
F2 and F3 are not connected. The LA10
detects automatically on F1 the mul-
tichannel mode. If not all functions of the
LA10 are required a Soundmodule SM7
can be connected and used in parallel.
On most radios/receivers channel 7 or 8
can be set to multichannel. Refer to
manual of your radio. The common
Robbe and Graupner radio extensions
have the following switch assignments:
