SG-2000 MANUAL 96
The SGC Building, 13737 S.E. 26th St. Bellevue, WA. 98005 USA
©1995, SGC, Inc. TEL: (206) 746-6310 FAX: (206) 746-6384
4. High Seas Direct Handset
Pin Item
1 Common mic
2 PTT In
3 Mic In
4 Audio Out
5 Scrambler activate
6 Ground PTT & Audio
Modem to Radio Connections:
High Sea Direct Modem SG-2000 SSB
Transceiver
Radio Port J301 Rear Panel Conn
Pin Item Pin Item
2 PTT <--connect--> 4 PTT
3 TX Out <--connect--> 1 Audio In
4 RX In <--connect--> 3 Audio Out
6 Ground <--connect--> 2 Ground
