17.3 RS-232 Software Main Menu Display
When the software is started, the Main Menu is displayed:
Channel 99 Mode A3H Time 14:32:50
RC FREQ 3860.0
TX FREQ 3860.0
VOC USB
FWD Power Power Setting HIGH
MENU 1
[A] CHANGE CHANNEL [F]ATTENUATOR
[B] CHANGE FREQUENCY [G]EMERGENCY ALARM
[C] PROGRAM [H] 2182 EMERGENCY
[D] SCAN [I] PREVIEW TX FREQUENCY
[E] CHANGE MODE [J] MENU 2
Radio operating parameters are displayed as follows:
Operating channel ___________________Upper left corner
Receive Frequency ___________________Upper left corner
Transmit Frequency__________________Upper left corner
Active Mode of Operation ____________Upper center
Current Date ________________________Upper right corner
Current Time _______________________Upper right corner
Active audio filter ___________________Middle right side
Active Sideband _____________________Middle right side
Meter selection ______________________Above left menu
Power setting _______________________Above right menu
