9.7 Additional Control Heads (Part No. 04-11)
Additional control heads may be added to the SG-2000 via the 10-pin connector located
under the protective cover on the rear panel of the radio. In the event more than one
additional control head is desired, a junction box is used. Please refer to the following
diagram:
REAR PANEL CONNECTION FOR ADDITIONAL CONTROL HEADS
Single control head
Junction Box for Additional Control Heads
SG-2000
Rear
J-503
