SG-2000 MANUAL 139
The SGC Building, 13737 S.E. 26th St. Bellevue, WA. 98005 USA
©1995, SGC, Inc. TEL: (206) 746-6310 FAX: (206) 746-6384
Internal cable from main radio unit to local control head
1
2
3
4
5
6
7
8
9
10
AUDIO
AUDIO
DATA
DATA
GND
PTT
OVEN
13.6VDC
SHLDS
ON/OFF
RED
BLK
ORE
YEL
BLU
GRN
VIO
SHLDS
SHLD
GRY
WHT
SGC P.N.
291-310
1
2
3
4
5
6
7
8
9
10
AUDIO
AUDIO
SHLDS
DATA
DATA
ON/OFF
PTT
GND
13.6VDC
WHT
GRY
SHLDS
VIO
GRN
BLU
YEL
ORE
BLK
SHLD
RED
OVEN
SGC P.N.
291-310
CUSTOM CABLE
SGC P.N. 881-017
21 inches
J20100152 CABLE ASSY TRANCEIVER =21 INCHES
TO HEAD
TO RADIO
