Object Point Var Description Format Range
Multiplier Units Comments
30 10 5 Watts, 3-Ph total SINT16 -32768 to +32767 (4500 / 32768)
W
30 11 5 VARs, 3-Ph total SINT16 -32768 to +32767 (4500 / 32768)
VAR
30 12 5 VAs, 3-Ph total SINT16 0 to +32767 (4500 / 32768)
VA
30 13 5 Power Factor, 3-Ph total SINT16 -1000 to +1000 0.001
none
30 14 5 Frequency SINT16 0 to 9999 0.01
Hz
30 15 5 Positive Watts, 3-Ph,
Maximum Avg Demand
SINT16 -32768 to +32767 (4500 / 32768)
W
30 16 5 Positive VARs, 3-Ph,
Maximum Avg Demand
SINT16 -32768 to +32767 (4500 / 32768)
VAR
30 17 5 Negative Watts, 3-Ph,
Maximum Avg Demand
SINT16 -32768 to +32767 (4500 / 32768)
W
30 18 5 Negative VARs, 3-Ph,
Maximum Avg Demand
SINT16 -32768 to +32767 (4500 / 32768)
VAR
30 19 5 VAs, 3-Ph, Maximum Avg
Demand
SINT16 -32768 to +32767 (4500 / 32768)
VA
30 20 5 Angle, Phase A Current SINT16 -1800 to +1800 0.1 degree
30 21 5 Angle, Phase B Current SINT16 -1800 to +1800 0.1 degree
30 22 5 Angle, Phase C Current SINT16 -1800 to +1800 0.1 degree
30 23 5 Angle, Volts A-B SINT16 -1800 to +1800 0.1 degree
30 24 5 Angle, Volts B-C SINT16 -1800 to +1800 0.1 degree
30 25 5 Angle, Volts C-A SINT16 -1800 to +1800 0.1 degree
30 26 5 CT numerator SINT16 1 to 9999 N/A none
CT ratio =
30 27 5 CT multiplier SINT16 1, 10, or 100 N/A none
(numerator * multiplier) / denominator
30 28 5 CT denominator SINT16 1 or 5 N/A none
30 29 5 PT numerator SINT16 1 to 9999 N/A none
PT ratio =
30 30 5 PT multiplier SINT16 1, 10, or 100 N/A none
(numerator * multiplier) / denominator
30 31 5 PT denominator SINT16 1 to 9999 N/A none
30 32 5 Neutral Current SINT16 0 to 32767 (10 / 32768) A
For 1A model, multiplier is (2 / 32768) and
values above 2A secondary read 32767.
80 0 1 Device Restart Bit N/A N/A N/A none Clear via Function 2 (Write), Qualifier Code
0.
