Sharp AL2020 Service Manual

AL-2020/2035/2040/2050/2060 FAX SOFT SWITCH 12 - 16
S
W
73
1 Inhibited to use 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
S
W
74
1 Print effective image area
sub scan lead edge void
Binary input
32 lines
0
2 Bit No.
Set range
1234
0 to 240 lines
16 lines interval (600dpi)
0
3 1
4 0
5 Inhibited to use 0
6 0
7 1
8 1
S
W
75
1 Manual calibration setting
when sending
1: ON 0: OFF
OFF 0
2 Manual calibration setting
when a signal arrives
1: ON 0: OFF
OFF 0
3 Communication end
sound (Buzzer sound
length) setting
Bit No. 3 4
3sec
0
Communication error
sound is generated
even in silent setup
Refer to User program
“BEEP LENGTH”.
When a value outside
the set range is set,
the initial value is set.
3sec 0 0
1sec 0 1
4 Silent 1 0
0
5 Print effective image area
main scan void
Binary input
48 dots
0
6 Bit No.
Set range
5678
0 to 240 dots
16 dots interval
0
7 1
8 1
S
W
76
1 Scan magnification ratio
adjustment (main scan)
flag
1: – 0: +
+0
2 Scan magnification ratio
adjustment (RSPF main
scan)
Binary input
0%
0
3 Bit No.
Set range
2345678
0 to ±12.7%
0.1% interval
0
4 0
5 0
6 0
7 0
8 0
S
W
77
1 Scan magnification ratio
adjustment (sub scan) flag
1: – 0: +
+0
2 Scan magnification ratio
adjustment (RSPF sub
scan)
Binary input
0%
0
3 Bit No.
Set range
2345678
0 to ±12.7%
0.1% interval
0
4 0
5 0
6 0
7 0
8 0
SW
NO.
Data
No.
Item Switch selection and contents of functions Initial value Remark
