AR-5520 SIMULATIONS 7-10
26 18 Toner save mode setting Used to set ON/OFF of the toner save mode.
* The toner save mode of the user program is also changed accordingly.
The default value depends on the destination.
30 CE mark conformity control ON/
OFF
When this simulation is executed, the current set code number of CE mark conformity is displayed.
Enter the desired code number of CE mark conformity and press the [START] key to set the code
number.
31 Auditor mode exclusive setup Used to set whether the bypass tray can be used or not when the auditor mode is set to the coin
vendor mode.
* When this is set to "Exclusive setup ON," if the auditor is set to the coin vendor mode and the
standard tray is set to the bypass tray, the standard tray must be set to the 1st tray.
36 Cancel of stop at maintenance life
over
Used to set stop at maintenance life over.
37 Cancel of stop at developer life
over
When this simulation is executed, the current set code number is displayed. Enter the desired code
number and press the [START] key to set the code number. The machine goes into the sub code
input state.
38 Cancel of stop at drum life over When this simulation is executed, the current set code number is displayed. Enter the desired code
number and press the [START] key to set the code number.
39 Memory capacity check When this simulation is executed, the current memory capacity is displayed.
42 Transfer ON/OFF timing control
setting
When this simulation is executed, the current setting value of transfer ON timing is displayed.
Enter a set value and press the [START] key to set the entered value, and the machine will go into
the sub code input standby mode.
When the [AUTO/TEXT/PHOTO] key is pressed, the ON timing setting and the OFF timing setting
are alternatively selected. At that time, the setting is saved and written into the EEPROM.
•Setting range: 1 ~ 99
When the setting value is increased by 1, time is increased by 2ms.
•The default, 38, of transfer ON timing means "320ms passed from PS release."
The default, 50, of transfer OFF timing means "304ms passed from P-IN OFF."
Main
code
Sub
code
Contents Details of operation
Code number Setting
0
1
Toner save OFF
Toner save ON
Code number Setting
0
1
CE mark conformity control OFF *Default for 100V system
CE mark conformity control ON *Default for 200V system
Code number Setting
0
1
3
Exclusive setup OFF (Bypass tray paper feed allowed)
Exclusive setup ON (Bypass tray paper fed inhibited)*Default
Exclusive setup OFF (Bypass tray paper fed inhibited)
(Double amount of that when set to "0" is charged.)
Code number Setting
0
1
Stop at maintenance life over
Cancel of stop at maintenance life over * Default
Code number Setting
0
1
Stop at developer life over
Cancel of stop at developer life over * Default
Code number Setting
0
1
Stop at drum life over
Cancel of stop at drum life over * Default
7-seg display Meaning (Memory capacity)
16
64
16MByte
64MByte
LED Setting mode Default
AUTO indicator
TEXT indicator
Transfer ON timing
Transfer OFF timing
38
50
To Next Page
