CD-BA3100
– 16 –
1. Motor assembly (x 2) mounting (screw x 4) 01/29 Fig.17
2. MT idle gear mounting (screw x 1) 25 Fig.17
3. MT system gear assembly 23/24/26/27 Fig.17
4. STB/tray drive system gear and others assembling/ 37/38/45/46 (53)/47/48 Fig.17
mounting (screw x 3)
5. Tray big gear assembly 31 Fig.17 Gear positioning
6. T.M SW PWB mounting (screw x 3) Fig.18
7. STB holder assembling 03 Fig.17
8. STB drive gear L/R assembly mounting (screw x 2) 11 (10)/12 (10) Fig.17
9. Tray joint gear R/tray drive gear R assembling 34/36 Fig.18 Gear positioning
10. Tray gear A/B assembling 32/33 Fig.18 Gear positioning
11. Lift gear B/C assembling 43/44 Fig.19 Gear positioning
12. MT idler gear F assembling, mode big gear 28/42 Fig.19
mounting (screw x 1)
13. Change box R mounting (screw x 4) 04 Fig.19
14. Lift gear A assembling 42 Fig.19 Gear positioning
15. Change box L assembly mounting (screw x 4) 02/30/35 Fig.20
16. Lift cam assembling (shaft inserting) 44 Fig.20 Gear positioning
17. STB holder height adjusting Fig.21 Check/adjustment
18. Top plate F/disc OB LEV. Mounting (screw x 6) 80 Fig.21
19. Trays 1 - 6 assembling 91/92/93/94/95/96 Fig.22
20. Top plate R mounting (screw x 6) ––
Applied part No.
Work content
Assembly fig. No.
Remarks
CD CHANGER MECHANISM MAIN BASE PARTS ASSEMBLING/ADJUSTING
PROCEDURE
01 (101) MAIN BASE
02 (102) CHANGE BOX L
03 (147) STB HOLDER
04 (103) CHANGE BOX R
10 (119) STB DRIVE GEAR A
11 (120) STB DRIVE GEAR L
12 (122) STB DRIVE GEAR R
20 (149) STABILIZER FH
23 (141) MT IDLER GEAR A
24 (138) MT IDLER GEAR B
25 (137) MT IDLER GEAR C
26 (140) MT IDLER GEAR D
27 (139) MT IDLER GEAR E
28 (131) MT IDLER GEAR F
29 (MOB1,2) MOTOR GEAR
30 (143) TRAY DRIVE GEAR F
31 (134) TRAY BIG GEAR
32 (135) TRAY GEAR A
33 (136) TRAY GEAR B
34 (124) TRAY DRIVE GEAR R
35 (144) TRAY JOINT GEAR F
36 (125) TRAY JOINT GEAR R
37 (142) TRAY GEAR C
38 (130) TRAY IDLER GEAR
Part name
No.
40 (115) LIFT CAM
41 (126) MODE BIG GEAR
42 (127) LIFT GEAR A
43 (128) LIFT GEAR B
44 (129) LIFT GEAR C
45 (132) STB GEAR A
46 (104) STB GEAR B
47 (133-1) STB GEAR C
48 (133-3) STB GEAR D
50 (145) LIFT LEVER
51 (106) TRAY LOCK LEVER
52 (118) DISC OB LEVER
53 (105) STB GEAR ANG.
80 (117) TOP PLATE F
81 (114) TOP PLATE R
91 (108) TRAY 1
92 (109) TRAY 2
93 (110) TRAY 3
94 (111) TRAY 4
95 (112) TRAY 5
96 (113) TRAY 6
Part name
No.
CD CHANGER MECHANISM PARTS LIST
The number of ( ) is the number of the parts guide.
