Sharp CD-BA3100 Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BA3100
207 GITAR0694AWSA J AQ Rear Panel [For Canada]
207 GITAR0695AWSA J AQ Rear Panel [For Mexico]
208 LANGK0188AWFW J AF Bracket,Fan Support
209 LANGK0236AWFW J AE Bracket,Heat Sink Left
210 LANGK0237AWFW J AE Bracket,Heat Sink Right
211 92LCSPR1431C J AA Spring,Ring
212 NFANP0001AWZZ J AD Rotary Fan
213 LANGK0256AWFW J AC Bracket,Cassette Lock [Tape 1]
214 LANGK0257AWFW J AC Bracket,Cassette Lock [Tape 2]
215 MLOKC0010AWZZ J Lever,Cassette Lock [Tape 1]
216 MLOKC0011AWZZ J AC Lever,Cassette Lock [Tape 2]
217 MSPRD0109AWFJ J AB Spring,Cassette Lock [Tape 1]
218 MSPRD0110AWFJ J AB Spring,Cassette Lock [Tape 2]
219 LHLDZ1333AWZZ J AC Holder,LED
220 PRDAR0184AWFW J AH Heat Sink,Sub
221 PRDAR0192AWFW J AV Heat Sink,Main
1 222 QACCD0022AWZZ J AM AC Power Supply Cord
223 QCNWN1860AWZZ J AC Lug Wire
224 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
225 QFSHD0001AWZZ J AB Holder,Fuse
226 92LNBAND1318A J AA Nylon Band,80mm
227 LCHSZ0021AWZZ J AL Chassis,Changer
228 KMECB0021AWZZ J BF Tape Mechanism Ass’y
228- 1 92PF513-860 J Head Plate Block [Tape 2]
228- 2 92PF525-338 J Motor with Pulley [Tape]
228- 3 92PF567-649 J Tape Mechanism PWB Ass’y
228- 4 92PFF19U-12 J Belt,Main [Tape 2]
228- 5 92PF514-135 J AL Pinch Roller
228- 6 92PF19S-31 J Belt,FF/REW [Tape 2]
228- 7 92PFF19N-11 J Belt,Main [Tape 1]
228- 8 92PF522-061 J Clutch Ass’y Block [Tape 1]
228- 9 92PFF19S-52 J Belt,FF/REW [Tape 2]
228-10 92PF513-861 J Head Plate Block [Tape 1]
228-11 92PF522-063 J Clutch Ass’y Block [Tape 2]
229 PCUSG0022AWZZ J AB Cushion,Leg
230 JKNBZ0784AWSA J AF Knob,Volume
231 LANGK0272AWFW J Bracket,Fan Support
601 LX-BZ2222AXZZ J AB Screw,Special
602 XEBSD30P08000 J AA Screw,ø3×8mm
603 XEBSD30P06000 J AA Screw,ø3×6mm
604 XEBSD30P14000 J AA Screw,ø3×14mm
605 LX-HZ0009AWFD J AC Screw,Special
606 XHBSD26P04000 J AA Screw,ø2.6×4mm
607 LX-LZ0006AWZZ J Holder,PWB
608 XESSD30P10000 J AA Screw,ø3×10mm
609 LX-HZ0082AFZZ J AA Screw,ø4×8mm
610 LX-JZ0010AFFD J AA Screw,ø3×10mm
611 XJBSD30P10000 J AA Screw,ø3×10mm
612 XJSSD30P10000 J AA Screw,ø3×10mm
613 XJBSD30P12000 J AA Screw,ø3×12mm
614 XBBSD20P04000 J AA Screw,ø2×4mm
617 XJBSD30P16000 J AA Screw,ø3×16mm
619 XJBSD30P08000 J Screw,ø3×8mm
620 LX-BZ0880AFZZ J Screw,ø × mm
PACKING PARTS (Except for U.S.A.)
SPAKA0296AWZZ J Packing Add.
SPAKC1130AWZZ J Packing Case
[For U.S.A./Central America]
SPAKC1131AWZZ J Packing Case [For Mexico]
SPAKC1132AWZZ J Packing Case [For Canada]
SPAKP0032AWZZ J AF Polyethylene Bag,Unit
SSAKA0007AWZZ J AB Polyethylene Bag,Accessories
ACCESSORIES
QANTL0007AWZZ J AK AM/FM Loop Antenna
TINSE0344AWZZ J AE Operation Manual
[For U.S.A./Central America]
TINSK0110AWZZ J Operation Manual [For Canada]
TINSZ0650AWZZ J AC Quick Guide
[For U.S.A./Central America]
TINSZ0655AWZZ J Operation Manual [For Mexico]
TLABN0112AWZZ J AA Label,Serial Number
TLABR1177AWZZ J AB Label,Bar Code
TLABZ0874AWZZ J AC Label,Feature [Tape 1]
TLABZ0875AWZZ J AC Label,Feature [Tape 2]
RRMCG0266AWSA J AQ Remote Control
J Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A 92LPWB3629MANS J –– Main
PWB-B1~4 92LPWB3629DPLS J –– Display/Eject Switch/Play Switch/
Headphones (Combined Ass’y)
PWB-C 92LPWB3629CDUS J –– CD Servo
PWB-D1~3 92LPWB3629PWRS J –– Power Amp./Power A/Power B
(Combined Ass’y)
PWB-E QPWBF0644AWZZ J AD Tray Switch (PWB Only)
PWB-F QPWBF0645AWZZ J AC Cam Switch (PWB Only)
PWB-G QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-H 92PF567-649 J –– Tape Mechanism
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner
– 6 –
CP-BA3100
SPEAKER BOX PARTS
901 HPNLS1021AWSA J AY Front Panel,Left
901 HPNLS1022AWSA J AY Front Panel,Right
902 CWAKP1046AWSA J AR Net Frame Ass’y
903 GBOXS2005AWSA J BF Speaker Box Ass’y,Right
903 GBOXS4005AWSA J BF Speaker Box Ass’y,Left
904 CPNLS1026AWSA J AX Sub Woofer Panel Ass’y,Left
904 CPNLS1028AWSA J AX Sub Woofer Panel Ass’y,Right
905 PCUSS0049AWZZ J AD Port Cushion
906 PCUSG0022AWZZ J AB Foot Cushion
907 LHLDZ8001AWSA J AD Catching Holder
908 QCNWN1834AWZZ J AK Tweeter Cord
(With Capacitor C1,2)
909 XJBSD40P20000 J AA Screw,ø4×20mm
910 XJBSD40P16000 J AB Screw,ø4×16mm
911 XJBSD30P10000 J AA Screw,ø3×10mm
912 XMBSD40P16000 J AC Screw,ø4×16mm
913 XMBSF40P20000 J AC Screw,ø4×20mm
914 PFLT-0046AWZZ J AC Felt
915 TSPC-0822AWZZ J AC Label,Specifications
916 QCNWN1912AWZZ J Sub Woofer Cord
917 QCNWN1835AWZZ J Woofer Cord
SP1,2 RSPA00010AW6T J AP Tweeter
SP3,4 RSPA10010AW6S J AX Woofer
SP5,6 RSPA10011AW6W J AY Sub Woofer
PACKING PARTS
SPAKA0298AWZZ J Packing Add.
SPAKZ0696AWZZ J Layer Pad
SSAKH0053AWZZ J AC Polyethylene Bag,Speaker
