PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BA3100
SW722 92LSWICH1401AT J AC Switch,Key Type [Disc 2 Eject]
SW723 92LSWICH1401AT J AC Switch,Key Type [Disc 3 Eject]
SW724 92LSWICH1401AT J AC Switch,Key Type [Disc 4 Eject]
SW727 92LSWICH1401AT J AC Switch,Key Type [Rewind]
SW728 92LSWICH1401AT J AC Switch,Key Type [Fast Forward]
SW729 92LSWICH1401AT J AC Switch,Key Type [Stop]
SW732 92LSWICH1401AT J AC Switch,Key Type [Play]
SW733 92LSWICH1401AT J AC Switch,Key Type [Clock]
SW734 92LSWICH1401AT J AC Switch,Key Type [Timer]
SW735 92LSWICH1401AT J AC Switch,Key Type [Tuner Up]
SW736 92LSWICH1401AT J AC Switch,Key Type [Tuner Down]
SW737 92LSWICH1401AT J AC Switch,Key Type [REC/Pause]
SW738 92LSWICH1401AT J AC Switch,Key Type [X-Bass]
SWB101 QSW-P9005AWZZ J AD Switch,Push Type
[Disc Detect 1]
SWB102 QSW-P9005AWZZ J AD Switch,Push Type
[Disc Detect 2]
SWB103 QSW-P9005AWZZ J AD Switch,Push Type
[Disc Detect 3]
SWB104 QSW-P9003AWZZ J AD Switch,Push Type [Mode 1]
SWB105 QSW-P9003AWZZ J AD Switch,Push Type [Mode 2]
SWB106 QSW-P9003AWZZ J AD Switch,Push Type [Mode 3]
SWB107 QSW-P9003AWZZ J AD Switch,Push Type [Mode 4]
SWB108 QSW-P9003AWZZ J AD Switch,Push Type [Mode 5]
SWB109 QSW-P9004AWZZ J AE Switch,Push Type [Tray 1]
SWB110 QSW-P9004AWZZ J AE Switch,Push Type [Tray 2]
WT601 QCNCW012EAWZZ J AC Socket,5Pin
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LMCUSN1524A J AD Cushion
1 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— –– Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
307 PCUSG0001AWSA J AD Cushion
308 PCUSG0004AWSA J AD Cushion
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
NM1 92LMTR2996CASY J AS Motor with Chassis [Spindle]
NM2 92LMTR1854BASY J AP Motor with Gear [Sled]
NSW1 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
CHANGER MECHANISM PARTS
101 LCHSM0106AWZZ J AQ Main Base
102 PGIDM0033AWZZ J AH Change Box,L
103 PGIDM0034AWZZ J AG Change Box,R
104 NGERH0121AWZZ J AC Gear,STB B
105 PGIDM0035AWZZ J AH Bracket,STB Gear
106 MLEVP0098AWZZ J AB Lever,Tray Lock
107 MSPRP0040AWFW J AD Spring,Tray Lock Lever
108 GCOVA1317AWZZ J AF Tray 1
109 GCOVA1318AWZZ J AF Tray 2
110 GCOVA1319AWZZ J AF Tray 3
111 GCOVA1320AWZZ J AF Tray 4
112 GCOVA1321AWZZ J AF Tray 5
113 GCOVA1322AWZZ J AF Tray 6
114 LPLTP0010AWZZ J AG Top Plate,R
115 MCAMP0009AWZZ J AE Cam,Lift
116 NSFTT0057AWFD J AE Shaft,Lift Cam
117 LPLTP0009AWZZ J AH Top Plate,F
118 MLEVP0099AWZZ J AB Lever,Disc OB
119 NGERH0098AWZZ J AC Gear,STB Drive,A
120 NGERH0099AWZZ J AC Gear,STB Drive,L
121 MLEVF0055AWFW J AC Lever,OS,L/R
122 NGERH0100AWZZ J AC Gear,STB Drive,R
123 MSPRT0040AWFJ J AB Spring,OS Lever
124 NGERH0111AWZZ J AC Gear,Tray Drive,R
125 NGERH0113AWZZ J AF Gear,Tray Joint,B
126 NGERH0116AWZZ J AH Gear,Mode Big
127 NGERH0117AWZZ J AC Gear,Lift A
128 NGERH0118AWZZ J AB Gear,Lift B
129 NGERH0119AWZZ J AF Gear,Lift C
130 NGERH0115AWZZ J AC Gear,Tray Idler
131 NGERH0106AWZZ J AC Gear,MT Idler,F
132 NGERH0120AWZZ J AB Gear,STB A
133 NSFTT0055AWM1 J AH STB Gear Ass’y
133- 1 NGERH0122AWZZ J AC Gear,STB C
133- 2 NSFTT0055AWFD J AG Shaft,STB Gear
133- 3 NGERH0123AWZZ J AC Gear,STB D
134 NGERH0108AWZZ J AK Gear,Tray Big
135 NGERH0109AWZZ J AB Gear,Tray A
136 NGERH0110AWZZ J AC Gear,Tray B
137 NGERH0103AWZZ J AB Gear,MT Idler,C
138 NGERH0102AWZZ J AC Gear,MT Idler,B
139 NGERH0105AWZZ J AB Gear,MT Idler,E
140 NGERH0104AWZZ J AB Gear,MT Idler,D
141 NGERH0101AWZZ J AD Gear,MT Idler,A
142 NGERH0114AWZZ J AB Gear,Tray C
143 NGERH0107AWZZ J AC Gear,Tray Drive,F
144 NGERH0112AWZZ J AF Gear,Tray Joint,F
145 MLEVP0097AWZZ J AB Lever,Left
146 NSFTT0056AWFD J AC Shaft,Lift Lever
147 LHLDZ1270AWZZ J AH Holder,STB
148 PMAGF0001AWZZ J AF Magnet
149 LHLDM1011AWZZ J AD STB FH
150 92LNBAND1318A J AA Nylon Band,80mm
151 QCNCW025DAWZZ J AB Holder,Flat Wire,4Pin
152 QCNCW025HAWZZ J AC Holder,Flat Wire,8Pin
801 XBPSD26P04000 J AA Screw,ø2.6×4mm
802 XEBSD20P07000 J AB Screw,ø2×7mm
803 XEBSD20P10000 J AA Screw,ø2×10mm
804 XHBSD20P05000 J AA Screw,ø2×5mm
805 LX-EZ0005AWFD J AA Screw,ø2.6×10mm
806 LX-EZ0026AWFD J AB Screw,ø2×9mm
807 LX-JZ0105AFFN J AA Screw,ø1.7×5mm
808 XEBSD30P10000 J AA Screw,ø3×10mm
MOB1 92LMTR3435DASY J AM Main Cam Motor Ass’y
MOB2 92LMTR3435DASY J AM Tray Motor Ass’y
CABINET PARTS
201 92LCAB3629AASY J Front Panel Ass’y
201- 1 ———— –– Front Panel
(Not Replacement Item)
201- 2 GDORF0101AWSA J AF Holder,Cassette [Tape 1]
201- 3 GDORF0102AWSA J AF Holder,Cassette [Tape 2]
201- 4 HDECQ0692AWSA J AE Panel,Cassette [Tape 1]
201- 5 HDECQ0693AWSA J AE Panel,Cassette [Tape 2]
201- 6 GCOVA1360AWSA J AH Cover,Cassette [Tape 1]
201- 7 GCOVA1361AWSA J AH Cover,Cassette [Tape 2]
201- 8 GDORF0103AWSA J AE Door,Changer
201- 9 HDECQ0694AWSA J AH Panel,Amp.
201-10 JKNBZ0785AWSA J AE Button,Power/Dimmer
201-11 JKNBZ0786AWSA J AF Button,Disc Number
201-12 JKNBZ0787AWSA J AD Button,Function
201-13 JKNBZ0788AWSA J AF Button,Play/Stop
201-14 JKNBZ0789AWSA J AF Button,Tuning
201-15 JKNBZ0790AWSA J AE Button,CD Eject
201-16 JKNBZ0791AWSA J AE Button,X-Bass
201-17 HDECQ0695AWSA J AG Panel,Top
201-18 GCOVA1362AWSA J AC Cover,Play/Stop
201-19 HDECQ0698AWSA J AE Panel,Changer Door
201-20 LHLDZ1335AWSA J AC Holder,Changer Door
201-21 MSPRD0160AWFJ J AB Spring,Changer Door
201-22 HDECQ0699AWSA J AG Panel,Main Control
201-23 GCOVA1363AWSA J AD Cover,Remote Sensor
201-24 GCOVA1364AWSA J AB Cover,Timer
201-25 HDECQ0708AWSA J AD Decoration Plate,Function
201-28 MLIFP0010AWZZ J AD Damper
201-29 HBDGB1001AWSA J AD Badge,SHARP
201-30 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
201-31 MSPRD0093AWFJ J AB Spring,Cassette,Tape 2
202 92LCAB3629BASY J Side Panel Ass’y,Left
202- 1 ———— –– Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3629CASY J Side Panel Ass’y,Right
203- 1 ———— –– Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1193AWSA J AN Cabinet,Top
205 LCHSM0124AWFW J AQ Main Chassis
206 LHLDZ1334AWZZ J AE Holder,FL Display
207 GITAR0668AWSA J AQ Rear Panel
[For U.S.A./Central America]
– 5 –
