Sharp CD-BA3100 Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BA3100
R804 VRD-ST2CD473J J AA 47 kohms,1/6W
R805 VRD-ST2EE223J J AA 22 kohms,1/4W
R806 VRD-ST2CD103J J AA 10 kohm,1/6W
R808 VRD-ST2CD151J J AA 150 ohms,1/6W
R809 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R819 VRD-ST2EE223J J AA 22 kohms,1/4W
R826 VRD-ST2CD224J J AA 220 kohms,1/6W
R827 VRD-ST2CD473J J AA 47 kohms,1/6W
R828 VRD-ST2CD101J J AA 100 ohm,1/6W
R829,830 VRD-ST2EE470J J AA 47 ohms,1/4W
R850 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R852 VRD-ST2EE223J J AA 22 kohms,1/4W
R853 VRD-ST2CD223J J AA 22 kohms,1/6W
R854 VRD-ST2CD103J J AA 10 kohm,1/6W
R855 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R856 VRD-ST2EE561J J AA 560 ohms,1/4W
1 R901 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R902 VRD-ST2CD223J J AA 22 kohms,1/6W
R903,904 VRD-ST2CD563J J AA 56 kohms,1/6W
R906,907 VRD-ST2CD561J J AA 560 ohms,1/6W
R908,909 VRD-ST2CD102J J AA 1 kohm,1/6W
1 R910 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R911,912 VRN-VV3AAR10J J AB 0.1 ohm,1W
R913,914 VRD-ST2CD102J J AA 1 kohm,1/6W
R915,916 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R917,918 VRD-ST2CD102J J AA 1 kohm,1/6W
R919~921 VRD-ST2CD563J J AA 56 kohms,1/6W
R922,923 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
1 R924,925 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R926 VRD-ST2CD223J J AA 22 kohms,1/6W
R927,928 VRD-ST2CD563J J AA 56 kohms,1/6W
R929,930 VRD-ST2CD821J J AA 820 ohms,1/6W
R931,932 VRD-ST2CD102J J AA 1 kohm,1/6W
R933,934 VRN-VV3AAR10J J AB 0.1 ohm,1W
R935,936 VRD-ST2CD103J J AA 10 kohm,1/6W
R937,938 VRD-ST2CD102J J AA 1 kohm,1/6W
R939~941 VRD-ST2CD563J J AA 56 kohms,1/6W
R942,943 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R944~947 VRD-RT2HD271J J AA 270 ohms,1/2W
R948~951 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R952 VRD-ST2CD153J J AA 15 kohms,1/6W
R953 VRD-ST2CD683J J AA 68 kohms,1/6W
R954 VRD-ST2CD102J J AA 1 kohm,1/6W
R955 VRD-RT2HD4R7J J AA 4.7 ohms,1/2W
R956,957 VRD-ST2CD183J J AA 18 kohms,1/6W
R970~975 VRD-ST2CD683J J AA 68 kohms,1/6W
R976,977 VRD-ST2CD102J J AA 1 kohm,1/6W
R979 VRD-ST2CD102J J AA 1 kohm,1/6W
R980 VRD-ST2CD103J J AA 10 kohm,1/6W
R993~996 VRN-VV3DAR22J J AC 0.22 ohms,2W
R997,998 VRD-ST2CD273J J AA 27 kohms,1/6W
RD01 VRD-ST2CD681J J AA 680 ohms,1/6W
RD02 VRD-ST2CD821J J AA 820 ohms,1/6W
RD03 VRD-MN2BD102J J AA 1 kohm,1/8W
RD04 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD05 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD06 VRD-MN2BD272J J AA 2.7 kohms,1/8W
RD07 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD08 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD09 VRD-MN2BD103J J AA 10 kohm,1/8W
RD10 VRD-MN2BD153J J AA 15 kohms,1/8W
RD11 VRD-MN2BD333J J AA 33 kohms,1/8W
RD12 VRD-MN2BD104J J AA 100 kohm,1/8W
RD13 VRD-ST2CD681J J AA 680 ohms,1/6W
RD14 VRD-MN2BD821J J AA 820 ohms,1/8W
RD15 VRD-MN2BD102J J AA 1 kohm,1/8W
RD16 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD17 VRD-ST2CD222J J AA 2.2 kohms,1/6W
RD18 VRD-ST2CD272J J AA 2.7 kohms,1/6W
RD19 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD20 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD21 VRD-MN2BD103J J AA 10 kohm,1/8W
RD22 VRD-MN2BD153J J AA 15 kohms,1/8W
RD25 VRD-MN2BD681J J AA 680 ohms,1/8W
RD26 VRD-MN2BD182J J AA 1.8 kohms,1/8W
RD28 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD29 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD30 VRD-MN2BD272J J AA 2.7 kohms,1/8W
RD31 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD32 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD33 VRD-MN2BD103J J AA 10 kohm,1/8W
RD34 VRD-MN2BD153J J AA 15 kohms,1/8W
RD35 VRD-MN2BD333J J AA 33 kohms,1/8W
RS709,710 VRD-MN2BD152J J AA 1.5 kohms,1/8W
OTHER CIRCUITRY PARTS
BI601/CNS601 QCNWN1850AWZZ J AF Connector Ass’y,6/6Pin
BI701/CNS905 QCNWN1846AWZZ J AH Connector Ass’y,8/8Pin
BI702/CNS702 QCNWN1847AWZZ J AD Connector Ass’y,2/2Pin
BI703A/B QCNWN1848AWZZ J AD Connector Ass’y,2/2Pin
BI704/CNS704 QCNWN1849AWZZ J AK Connector Ass’y,12/12Pin
BI901/CNS901 QCNWN1851AWZZ J AG Connector Ass’y,7/7Pin
BI902/CNS902 QCNWN1852AWZZ J AF Connector Ass’y,5/5Pin
CNP1 QCNCM704GAWZZ J AC Plug,7Pin
CNP2 QCNCM704HAWZZ J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP4 92LCONE4P53254 J AC Plug,4Pin
CNP5 QCNCW026DAWZZ J AC Socket,4Pin
CNP6 QCNCW026HAWZZ J AC Socket,8Pin
CNP7 QCNCM932MAFZZ J AE Plug,12Pin
CNP8 92LCONE6P53254 J AC Plug,6Pin
CNP101 QCNCM705CAFZZ J AA Plug,3Pin
CNP102 QCNCM705GAFZZ J AB Plug,7Pin
CNP301 92LCONE3P5268 J AC Plug,3Pin
CNP602 QCNCWZP15AWZZ J AC Socket,15Pin
CNP701 QCNCWZY08AWZZ J AC Socket,8Pin
CNP702 QCNCWZF15AWZZ J Socket,15Pin
CNP704 92LCONE2P53254 J AB Plug,2Pin
CNP806 QCNCW010JAWZZ J AC Plug,9Pin
CNP901 92LCONE7P53253 J AC Plug,7Pin
CNP902 92LCONE5P5267X J AB Plug,5Pin
CNP904 92LCONE2P53253 J AB Plug,2Pin
CNP905 92LCONE9P53253 J AC Plug,9Pin
CNP906 QCNCM010JAWZZ J AC Socket,9Pin
CNP907 92LCONE2P53253 J AB Plug,2Pin
CNS1A/B QCNWN1689AWZZ J AF Connector Ass’y,7/7Pin
CNS2A/B QCNWN1690AWZZ J AG Connector Ass’y,8/8Pin
CNS3A/B QCNWN1688AWZZ J AF Connector Ass’y,6/6Pin
CNS4 QCNWN1692AWZZ J AD Connector Ass’y,4Pin
CNS904 QCNWN1841AWZZ J AD Connector Ass’y,2Pin
CNS907 QCNWN1955AWZZ J AD Connector Ass’y,2Pin
1 F800,801 QFS-D402DAWNI J AC Fuse,4A/125V
1 F802,803 QFS-D502DAWNI J AC Fuse,5A/125V
1 F804,805 QFS-D202DAWNI J AC Fuse,2A/125V
1 F806 QFS-D502DAWNI J AC Fuse,5A/125V
FFC701 QCNWN1838AWZZ J AD Flat Cable,8Pin
FFC702 QCNWN1857AWZZ J AF Flat Cable,15Pin
FL701 VVKNA16LM17-1 J BC FL Display
FW2 QCNWN1691AWZZ J AD Flat Wire,8Pin
FW3 QCNWN1693AWZZ J AC Flat Wire,4Pin
FW901 QCNWN1853AWZZ J AD Flat Wire,5Pin
JK601 QSOCJ0219AWZZ J AD Jack,Video/AUX In
JK670 QJAKM0004AWZZ J AK Jack,Headphones
JOG701 QSW-Z0014AWZZ J AF Switch,Push Type [Jog Volume]
LG901 QLUGP0001AWZZ J AC Lug
M901,902 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
MOB1 92LMTR3435DASY J AM Main Cam Motor Ass’y
MOB2 92LMTR3435DASY J AM Tray Motor Ass’y
NM1 92LMTR2996CASY J AS Motor with Chassis [Spindle]
NM2 92LMTR1854BASY J AP Motor with Gear [Sled]
NSW1 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
RY901,902 RRLYD0014AWZZ J AK Relay
SO901 QTANA0810AWZZ J AF Terminal,Speaker
SW701 92LSWICH1401AT J AC Switch,Key Type [Power]
SW706 92LSWICH1401AT J AC Switch,Key Type [Disc 1 Play]
SW707 92LSWICH1401AT J AC Switch,Key Type [Disc 2 Play]
SW708 92LSWICH1401AT J AC Switch,Key Type [Disc 3 Play]
SW709 92LSWICH1401AT J AC Switch,Key Type [Disc 4 Play]
SW710 92LSWICH1401AT J AC Switch,Key Type [Disc 5 Play]
SW711 92LSWICH1401AT J AC Switch,Key Type [Disc 6 Play]
SW712 92LSWICH1401AT J AC Switch,Key Type [Disc 5 Eject]
SW713 92LSWICH1401AT J AC Switch,Key Type [Disc 6 Eject]
SW714 92LSWICH1401AT J AC Switch,Key Type [Dimmer]
SW715 92LSWICH1401AT J AC Switch,Key Type [CD]
SW716 92LSWICH1401AT J AC Switch,Key Type [Tape]
SW717 92LSWICH1401AT J AC Switch,Key Type [Tuner]
SW718 92LSWICH1401AT J AC Switch,Key Type [Video]
SW719 92LSWICH1401AT J AC Switch,Key Type [Memory]
SW720 92LSWICH1401AT J AC Switch,Key Type [Equalizer]
SW721 92LSWICH1401AT J AC Switch,Key Type [Disc 1 Eject]
– 4 –
