Sharp CD-BA3100 Service Manual

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BA3100
R10 VRD-ST2CD103J J AA 10 kohm,1/6W
R11 VRD-ST2CD331J J AA 330 ohms,1/6W
R12 VRD-ST2CD123J J AA 12 kohms,1/6W
R13~19 VRD-ST2CD102J J AA 1 kohm,1/6W
R21 VRD-ST2CD221J J AA 220 ohms,1/6W
R22 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R23 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R24 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R25 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R26 VRD-ST2CD101J J AA 100 ohm,1/6W
R27,28 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R29~36 VRD-ST2CD102J J AA 1 kohm,1/6W
R37,38 VRD-ST2CD681J J AA 680 ohms,1/6W
R39 VRD-ST2CD123J J AA 12 kohms,1/6W
R40 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R41 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R42 VRD-ST2CD153J J AA 15 kohms,1/6W
R43 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R44 VRD-ST2CD153J J AA 15 kohms,1/6W
R45 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R46 VRD-ST2CD153J J AA 15 kohms,1/6W
R47 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R48 VRD-ST2CD153J J AA 15 kohms,1/6W
R49 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R50 VRD-ST2CD153J J AA 15 kohms,1/6W
R51,52 VRD-ST2CD101J J AA 100 ohm,1/6W
R53 VRD-ST2CD103J J AA 10 kohm,1/6W
R54~63 VRD-ST2CD102J J AA 1 kohm,1/6W
R101 VRD-MN2BD102J J AA 1 kohm,1/8W
R102 VRD-ST2CD102J J AA 1 kohm,1/6W
R103,104 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R105,106 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R107,108 VRD-MN2BD473J J AA 47 kohms,1/8W
R109,110 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R111,112 VRD-MN2BD153J J AA 15 kohms,1/8W
R113,114 VRD-MN2BD103J J AA 10 kohm,1/8W
R115 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R117,118 VRD-MN2BD102J J AA 1 kohm,1/8W
R119 VRD-ST2CD560J J AA 56 ohms,1/6W
R120 VRD-MN2BD560J J AA 56 ohms,1/8W
R121,122 VRD-MN2BD104J J AA 100 kohm,1/8W
R123,124 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R125,126 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R131,132 VRD-MN2BD333J J AA 33 kohms,1/8W
R134 VRD-MN2BD683J J AA 68 kohms,1/8W
R135,136 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R137 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R138 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R139,140 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R141,142 VRD-MN2BD101J J AA 100 ohm,1/8W
R145,146 VRD-MN2BD103J J AA 10 kohm,1/8W
R153,154 VRD-MN2BD103J J AA 10 kohm,1/8W
R155 VRD-ST2EE151J J AA 150 ohms,1/4W
R156 VRD-ST2CD224J J AA 220 kohms,1/6W
R157 VRD-MN2BD224J J AA 220 kohms,1/8W
R158 VRD-ST2EE221J J AA 220 ohms,1/4W
R160 VRD-RT2HD820J J AA 82 ohms,1/2W
R162 VRD-MN2BD473J J AA 47 kohms,1/8W
R164 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R166 VRD-MN2BD223J J AA 22 kohms,1/8W
R167 VRD-MN2BD473J J AA 47 kohms,1/8W
R168 VRD-ST2CD4R7J J AA 4.7 ohms,1/6W
R169~174 VRD-MN2BD102J J AA 1 kohm,1/8W
R309 VRD-ST2CD103J J AA 10 kohm,1/6W
R311 VRD-MN2BD104J J AA 100 kohm,1/8W
R313 VRD-MN2BD333J J AA 33 kohms,1/8W
R314 VRD-ST2CD220J J AA 22 ohms,1/6W
R316 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R322 VRD-MN2BD681J J AA 680 ohms,1/8W
R323 VRD-MN2BD683J J AA 68 kohms,1/8W
R325 VRD-MN2BD473J J AA 47 kohms,1/8W
R327 VRD-MN2BD330J J AA 33 ohms,1/8W
R336 VRD-MN2BD103J J AA 10 kohm,1/8W
R350 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R351 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R352 VRD-MN2BD102J J AA 1 kohm,1/8W
R353 VRD-MN2BD271J J AA 270 ohms,1/8W
R355 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R356 VRD-MN2BD102J J AA 1 kohm,1/8W
R357 VRD-ST2CD474J J AA 470 kohms,1/6W
R358 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R359 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R360 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R365 VRD-MN2BD103J J AA 10 kohm,1/8W
R372~374 VRD-MN2BD102J J AA 1 kohm,1/8W
R375 VRD-ST2CD471J J AA 470 ohms,1/6W
R376 VRD-MN2BD102J J AA 1 kohm,1/8W
R377 VRD-MN2BD473J J AA 47 kohms,1/8W
R378 VRD-MN2BD102J J AA 1 kohm,1/8W
R379 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R380 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R381 VRD-MN2BD103J J AA 10 kohm,1/8W
R382 VRD-ST2EE151J J AA 150 ohms,1/4W
R383 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R384 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R385 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R386 VRD-ST2CD223J J AA 22 kohms,1/6W
R387 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R388 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R391,392 VRD-ST2EE271J J AA 270 ohms,1/4W
R393 VRD-MN2BD102J J AA 1 kohm,1/8W
R395 VRD-MN2BD473J J AA 47 kohms,1/8W
R605,606 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R607 VRD-MN2BD103J J AA 10 kohm,1/8W
R608 VRD-ST2CD103J J AA 10 kohm,1/6W
R609,610 VRD-ST2CD331J J AA 330 ohms,1/6W
R611 VRD-MN2BD273J J AA 27 kohms,1/8W
R612 VRD-ST2CD273J J AA 27 kohms,1/6W
R613,614 VRD-MN2BD391J J AA 390 ohms,1/8W
R615,616 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R619 VRD-MN2BD223J J AA 22 kohms,1/8W
R623,624 VRD-MN2BD103J J AA 10 kohm,1/8W
R625,626 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R631,632 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R633,634 VRD-MN2BD333J J AA 33 kohms,1/8W
R637,638 VRD-MN2BD184J J AA 180 kohms,1/8W
R641~643 VRD-ST2CD102J J AA 1 kohm,1/6W
R700 VRD-MN2BD102J J AA 1 kohm,1/8W
R701,702 VRD-ST2CD473J J AA 47 kohms,1/6W
R703 VRD-MN2BD823J J AA 82 kohms,1/8W
R704~706 VRD-MN2BD104J J AA 100 kohm,1/8W
R707 VRD-MN2BD330J J AA 33 ohms,1/8W
R708~710 VRD-MN2BD102J J AA 1 kohm,1/8W
R711 VRD-MN2BD104J J AA 100 kohm,1/8W
R712 VRD-MN2BD473J J AA 47 kohms,1/8W
R713~717 VRD-MN2BD103J J AA 10 kohm,1/8W
R718~728 VRD-MN2BD102J J AA 1 kohm,1/8W
R730 VRD-MN2BD102J J AA 1 kohm,1/8W
R731 VRD-ST2CD102J J AA 1 kohm,1/6W
R732 VRD-ST2CD101J J AA 100 ohm,1/6W
R733~736 VRD-ST2CD102J J AA 1 kohm,1/6W
R737,738 VRD-MN2BD102J J AA 1 kohm,1/8W
R739 VRD-ST2CD102J J AA 1 kohm,1/6W
R740 VRD-MN2BD102J J AA 1 kohm,1/8W
R741 VRD-ST2CD102J J AA 1 kohm,1/6W
R742 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R743 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R744 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R745 VRD-ST2CD103J J AA 10 kohm,1/6W
R746,747 VRD-MN2BD102J J AA 1 kohm,1/8W
R749,750 VRD-ST2CD102J J AA 1 kohm,1/6W
R758~760 VRD-MN2BD102J J AA 1 kohm,1/8W
R761,762 VRD-MN2BD103J J AA 10 kohm,1/8W
R763 VRD-MN2BD102J J AA 1 kohm,1/8W
R765 VRD-MN2BD102J J AA 1 kohm,1/8W
R766 VRD-MN2BD103J J AA 10 kohm,1/8W
R767 VRD-MN2BD102J J AA 1 kohm,1/8W
R769 VRD-ST2CD102J J AA 1 kohm,1/6W
R770,771 VRD-MN2BD101J J AA 100 ohm,1/8W
R773 VRD-MN2BD102J J AA 1 kohm,1/8W
R778 VRD-MN2BD473J J AA 47 kohms,1/8W
R779~781 VRD-MN2BD103J J AA 10 kohm,1/8W
R783 VRD-MN2BD473J J AA 47 kohms,1/8W
R784 VRD-MN2BD104J J AA 100 kohm,1/8W
R785 VRD-ST2CD101J J AA 100 ohm,1/6W
R786~788 VRD-MN2BD103J J AA 10 kohm,1/8W
R790~795 VRD-MN2BD103J J AA 10 kohm,1/8W
R796 VRD-MN2BD473J J AA 47 kohms,1/8W
R797 VRD-MN2BD103J J AA 10 kohm,1/8W
R798 VRD-ST2CD103J J AA 10 kohm,1/6W
R799 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R801 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R802 VRD-ST2EE100J J AA 10 ohm,1/4W
R803 VRD-ST2CD123J J AA 12 kohms,1/6W
– 3 –
