Sharp CD-BA3100 Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BA3100
C119,120 VCKYMN1HB561K J AA 560 pF,50V
C121,122 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C123,124 VCTYMN1CX222K J AA 0.0022 µF,16V
C127 VCTYMN1EF223Z J AA 0.022 µF,25V
C128 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C131,132 VCKYMN1HB271K J AA 270 pF,50V
C133,134 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C135,136 VCTYPA1CX223K J AA 0.022 µF,16V
C139,140 VCTYMN1CX332K J AA 0.0033 µF,16V
C141,142 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C145 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C146 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C150 VCQPKA2AA822J J AA 0.0082 µF,100V,Polypropylene
C151 VCQYKA1HM393K J AB 0.039 µF,50V,Mylar
C152 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C153 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C154 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C155 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C156 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C157 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C301 VCKYMN1HB102K J AA 0.001 µF,50V
C303 VCCCMN1HH100J J AA 10 pF (CH),50V
C304 VCTYMN1CY103N J AA 0.01 µF,16V
C305 VCCCMN1HH4R7C J AA 4.7 pF (CH),50V
C306 VCTYMN1EF223Z J AA 0.022 µF,25V
C307 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C308 VCCUMN1HJ4R7D J AA 4.7 pF (UJ),50V
C309 VCKYMN1HB102K J AA 0.001 µF,50V
C310 VCCCMN1HH150J J AA 15 pF (CH),50V
C311 VCCSMN1HL180J J AA 18 pF,50V
C312 VCTYMN1EF223Z J AA 0.022 µF,25V
C313 VCCCMN1HH220J J AA 22 pF (CH),50V
C314,315 VCTYMN1CX472K J AA 0.0047 µF,16V
C316 VCTYMN1EF223Z J AA 0.022 µF,25V
C317 VCKYMN1HB102K J AA 0.001 µF,50V
C318 VCKYMN1HB101K J AA 100 pF,50V
C320 VCKYBT1HB102K J AA 0.001 µF,50V
C323 VCTYMN1EF223Z J AA 0.022 µF,25V
C324 VCCUMN1HJ3R9K J AA 3.9 pF (UJ),50V
C330 VCCSMN1HL150J J AA 15 pF,50V
C331 VCKYPA1HF473Z J AB 0.047 µF,50V
C332 VCTYMN1EF223Z J AA 0.022 µF,25V
C334 VCCUMN1HJ270J J AA 27 pF (UJ),50V
C335 VCKYMN1HB561K J AA 560 pF,50V
C338 VCKYMN1HB102K J AA 0.001 µF,50V
C342 VCTYMN1EF223Z J AA 0.022 µF,25V
C350,351 VCTYMN1EF223Z J AA 0.022 µF,25V
C352 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C353,354 VCTYMN1EF223Z J AA 0.022 µF,25V
C355 VCCSMN1HL220J J AA 22 pF,50V
C356 VCKYMN1HB102K J AA 0.001 µF,50V
C357 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C358 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C361 VCTYMN1EF223Z J AA 0.022 µF,25V
C362 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C363 VCTYMN1EF223Z J AA 0.022 µF,25V
C364 VCEAZA1HW475M J AB 4.7 µF,50V,Electrolytic
C365 VCTYPA1CX223K J AA 0.022 µF,16V
C366 VCKYMN1HB102K J AA 0.001 µF,50V
C367,368 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C369 VCCUMN1HJ270J J AA 27 pF (UJ),50V
C370~372 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C373,374 VCTYPA1CX153K J AA 0.015 µF,16V
C380 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C381 VCCCMN1HH120J J AA 12 pF (CH),50V
C382 VCCCMN1HH150J J AA 15 pF (CH),50V
C384 VCKYMN1HB102K J AA 0.001 µF,50V
C385 VCTYMN1CY103N J AA 0.01 µF,16V
C386 VCKYMN1HB331K J AA 330 pF,50V
C387 VCTYMN1EF223Z J AA 0.022 µF,25V
C388 VCKYMN1HB102K J AA 0.001 µF,50V
C391 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C392 VCKYMN1HB102K J AA 0.001 µF,50V
C393 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C394 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C395 VCTYMN1EF223Z J AA 0.022 µF,25V
C396 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C397 VCTYMN1EF223Z J AA 0.022 µF,25V
C398 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C399 VCTYMN1EF223Z J AA 0.022 µF,25V
C602 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C604 VCTYMN1EF223Z J AA 0.022 µF,25V
C606 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C607~610 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C611,612 VCQYKA1HM272K J AA 0.0027 µF,50V,Mylar
C613,614 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C617 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C619~630 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C631,632 VCKYMN1HB391K J AA 390 pF,50V
C634 VCKYMN1HB102K J AA 0.001 µF,50V
C701 VCTYMN1EF223Z J AA 0.022 µF,25V
C702 RC-EZD476AF1E J AC 47 µF,25V,Electrolytic
C703 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C704 VCTYMN1EF223Z J AA 0.022 µF,25V
C705 RC-EZD476AF1E J AC 47 µF,25V,Electrolytic
C706 VCTYMN1EF223Z J AA 0.022 µF,25V
C707~710 VCKYBT1HF104Z J AC 0.1 µF,50V
C711 VCCSMN1HL180J J AA 18 pF,50V
C712 VCCSMN1HL150J J AA 15 pF,50V
C713 VCTYMN1EF223Z J AA 0.022 µF,25V
C714 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C715 VCTYMN1EF223Z J AA 0.022 µF,25V
C716,717 VCKYMN1HB102K J AA 0.001 µF,50V
C722 RC-EZD335AF1H J AB 3.3 µF,50V,Electrolytic
C723,724 VCTYMN1EF223Z J AA 0.022 µF,25V
C725 RC-EZD476AF1E J AC 47 µF,25V,Electrolytic
C726 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C727 VCKYMN1HB391K J AA 390 pF,50V
C801,802 VCEAZW1HW228M J AH 2200 µF,50V,Electrolytic
C803~806 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C807,808 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C809 VCEAZA1HW227M J AC 220 µF,50V,Electrolytic
C810,811 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C812 VCEAZA1VW107M J AC 100 µF,35V,Electrolytic
C813,814 RC-EZ0063AWZZ J AM 2200/63,Electrolytic
C825 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C830 VCEAZA0JW108M J AC 1000 µF,6.3V,Electrolytic
C832,833 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C850 VCEAZW1VW228M J AH 2200 µF,35V,Electrolytic
C851 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C852 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C855 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C857 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C858 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C860 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C861 VCEAZW1CW478M J AG 4700 µF,16V,Electrolytic
C901,902 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C903,904 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C905 VCKZPA1HF223Z J AA 0.022 µF,50V
C906,907 VCCSPA1HL221J J AA 220 pF,50V
C908 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C909,910 VCCSPA1HL150J J AA 15 pF,50V
C911 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C912 VCKZPA1HF223Z J AA 0.022 µF,50V
C914 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C916~919 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C920,921 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C922,923 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C924,925 VCKZPA1HF223Z J AA 0.022 µF,50V
C926,927 VCTYPA1EX152K J AA 0.0015 µF,25V
C928,929 VCCSPA1HL150J J AA 15 pF,50V
C930,931 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C932 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C935,936 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C938 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C939,940 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C941,942 VCQYKA1HM123K J AA 0.012 µF,50V,Mylar
C943,944 VCKYPA1HB102K J AA 0.001 µF,50V
C954,955 VCQYKA1HM823K J AC 0.082 µF,50V,Mylar
C958,959 VCEAZA1HW224M J AB 0.22 µF,50V,Electrolytic
C960,961 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C990,991 VCEAZA1HW224M J AB 0.22 µF,50V,Electrolytic
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
R1 VRD-ST2CD333J J AA 33 kohms,1/6W
R2,3 VRD-ST2CD123J J AA 12 kohms,1/6W
R4 VRD-ST2CD333J J AA 33 kohms,1/6W
R5,6 VRD-ST2CD123J J AA 12 kohms,1/6W
R7 VRD-ST2CD470J J AA 47 ohms,1/6W
R8 VRD-ST2CD3R3J J AA 3.3 ohms,1/6W
R9 VRD-ST2CD273J J AA 27 kohms,1/6W
– 2 –
