Sharp CD-BA3100 Service Manual

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BA3100
CD-BA3100
INTEGRATED CIRCUITS
IC1 VHILC78645E-1 J AY CD Servo,LC78645E
IC2 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled Driver,
M63001FP
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC701 RH-IX0400AWZZ J AZ System Microcomputer,
IX0400AW
IC702 VHID16315GB-1 J AM ,D16315GB
IC703 VHIBA3835F/-1 J AS Band Pass Filter,BA3835F
IC901 VHISTK40270N1 J AY Power Amp.,STK40270N
IC902 VHISTK40270N1 J AY Power AMP.,STK40270N
TRANSISTORS
Q1 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q2 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q3~12 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q103~106 VS2SC1845F/-1 J AC Silicon,NPN,2SC1845 F
Q107,108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110,111 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q121,122 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q124 VS2SA1015GR-1 J AB Silicon,PNP,2SA1015 GR
Q126 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q128 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q302 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q603,604 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701~703 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q704~706 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q707 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q708,709 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q801 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q850 VSKTC2026//-1 J AF Silicon,NPN,KTC2026
Q851 VHIKIA7810AP1 J AF Voltage Regulator,KIA7810 AP
Q852 VHIKIA7805AP1 J AF Constant Voltage Regulator,
KIA7805 AP
Q901~909 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q910 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q990 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q991 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
DIODES
D301,302 VHDDS1SS133-1 J AB Silicon,DS1SS133
D305 VHDDS1SS133-1 J AB Silicon,DS1SS133
D601,602 VHDDS1SS133-1 J AB Silicon,DS1SS133
D711~718 VHDDS1SS133-1 J AB Silicon,DS1SS133
D801 VHDDS1SS133-1 J AB Silicon,DS1SS133
D802,803 VHDTS6B04GM-1 J AP Silicon,TS6B04GM
D804~809 VHDDS1N404S-1 J AB Silicon,DS1N404S
D818 VHDDS1N404S-1 J AB Silicon,DS1N404S
D819,820 VHDDS1SS133-1 J AB Silicon,DS1SS133
D901~907 VHDDS1SS133-1 J AB Silicon,DS1SS133
D909 VHDDS1SS133-1 J AB Silicon,DS1SS133
DZ801A VHEDZ2R4BSB-1 J AB Zener,2.4V,DZ2.4BSB
LED701 VHP4204SRT121 J AD LED,Red,4204SRT121
LED710,711 VHP4204UYT121 J AD LED,Yellow,4204UYT121
ZD1 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD2 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD801B VHEDZ300BSC-1 J AB Zener,30V,DZ300BSC
ZD802 VHEDZ6R2BSA-1 J AB Zener,6.2V,DZ6.2BSA
ZD806 VHEDZ110BSB-1 J AB Zener,11V,DZ110BSB
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF303 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
T301 RCILB0065AWZZ J AC FM OSC.
T302 RCILI0017AWZZ J AB FM IF
T303 RCILA0052AWZZ J AE AM Tracking
T306 RCILB0067AWZZ J AD AM OSC.
T351 RCILI0019AWZZ J AD AM IF
1 T801 RTRNP0357AWZZ J BF Power
COILS
L2 VP-XHR82K0000 J AC 0.82 µH
L104 VP-MK331K0000 J AB 330 µH,Choke
L312 RCILR0056AWZZ J AB FM RF
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L902~905 RCILZ0137AFZZ J AA 0.29 µH
VARIABLE CAPACITORS
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302 VHCSVC211C/-1 J AG Variable Capacitance,SVC211C
VD303 VHCSVC211C/-1 J AG Variable Capacitance,SVC211C
VIBRATORS
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0019AWZZ J AF Crystal,4.5 MHz
XL1 RCRM-0041AWZZ J AF Ceramic,33.8688 MHz
XL701 RCRSP0026AWZZ J AG Crystal,4.194304 MHz
CAPACITORS
C1 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C2 VCTYPA1CX103K J AA 0.01 µF,16V
C3 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C4 VCKYPA1HB102K J AA 0.001 µF,50V
C5 VCTYPA1CX473K J AA 0.047 µF,16V
C6 VCTYPA1CX104K J AB 0.1 µF,16V
C7 VCKYPA1HB101K J AA 100 pF,50V
C8 VCKYPU1HB472K J AA 0.0047 µF,50V
C9 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C10 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C11 VCEAZA1HW224M J AB 0.22 µF,50V,Electrolytic
C12 VCKYPA1HB101K J AA 100 pF,50V
C13 VCTYPA1CX103K J AA 0.01 µF,16V
C14 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C15 VCEAZA1CW227M J AC 220 µF,16V,Electrolytic
C16 VCTYPA1CX473K J AA 0.047 µF,16V
C17 VCEAZA1CW477M J AC 470 µF,16V,Electrolytic
C18 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C23 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C24 VCKZPA1HF223Z J AA 0.022 µF,50V
C25 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C27 VCKYPU1HB472K J AA 0.0047 µF,50V
C28 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C29 VCEAZA0JW337M J AC 330 µF,6.3V,Electrolytic
C30 VCKZPA1HF223Z J AA 0.022 µF,50V
C31 VCKYPU1HB472K J AA 0.0047 µF,50V
C32 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C37 VCTYPA1CX473K J AA 0.047 µF,16V
C38 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C39 VCTYPA1CX104K J AB 0.1 µF,16V
C40 VCKZPA1HF223Z J AA 0.022 µF,50V
C41,42 VCKYPA1HB101K J AA 100 pF,50V
C43 VCKYPA1HB101K J AA 100 pF,50V
C44 VCKYPA1HB101K J AA 100 pF,50V
C45~47 VCKYPA1HB101K J AA 100 pF,50V
C48 VCTYPA1CX103K J AA 0.01 µF,16V
C51 VCKYBT1HB102K J AA 0.001 µF,50V
C52 VCTYPA1CX103K J AA 0.01 µF,16V
C53 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C54 VCCCPA1HH220J J AA 22 pF (CH),50V
C55,56 VCTYBT1HB102K J AA 0.001 µF,50V
C101,102 VCKYMN1HB561K J AA 560 pF,50V
C105 VCKYBT1HB181K J AA 180 pF,50V
C106 VCKYMN1HB181K J AA 180 pF,50V
C107,108 VCKYMN1HB561K J AA 560 pF,50V
C111~114 VCKYMN1HB331K J AA 330 pF,50V
C115,116 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C117,118 VCTYPA1EX333K J AA 0.033 µF,25V
– 1 –
