Sharp HT-SB116 User Manual

E-9
Sound bar preparation (continued)
 Installing the sound bar
1. Mark two screw points on the
wall as below distance.
2. Make a hole on the wall
following the screw point
marks by using a drill.
3. Fix a wall mount plug into the
hole using a hammer, until it is
ushed with the wall surface.
403 mm
Ø5.5 ~ 6mm
32m
Wall
surface
1-1/4" (32 mm)
3/8"
(8-9 mm)
Wall
surface
1-1/4" (32 mm)
3/8"
(8-9 mm)
4. Fasten the screws to the wall
as shown below. (Total screw
is 2 pieces)
5. Hang the sound bar onto the
screws.
Screw using
Wall surface
a screwdriver
4.5mm - 5mm
Gap from
wall surface
