Installation image:
Place the system as shown.
Note:
The front panel of the sound bar is
not removable.
Caution:
● Do not change the installation
direction when the sound bar is
turned on.
● Do not stand or sit on the sound
bar as you may be injured.
● Do not allow any objects to fall into
or to be placed in the bass reex
duct.
Safety wires (not supplied) are useful
to prevent the sound bar from falling.
Placing the system Falling prevention
Sound Bar
Digital Tuner BD player
Safety wires
(not supplied)
Screw eye (not supplied)
Sound bar
Wall
When mounting on the wall
When placing on the shelf/
table
Sound bar
Safety wires
(not supplied)
Screw eyes
(not supplied)
Shelf or
table
