E-8
Cautions:
● Be very careful to prevent the
sound bar [1.7 kg (3.7 lbs.)] from
falling when mounting on the wall.
● Before mounting, check the wall
strength. (Do not put on the
veneer plaster or whitewashed
wall. The sound bar may fall.)
If unsure, consult a qualied
service technician.
● Mounting screws are not
supplied. Use appropriate ones.
● Check all wall mount angle
screws for looseness.
● Select a good location. If not,
accidents may occur or the sound
bar may get damaged.
● SHARP is not responsible
for accidents resulting from
improper installation.
SHARP designed the sound bar so
you may hang it on the wall. Use
proper screws (not supplied). See
below for size and type.
Sound bar preparation
Make sure to unplug the AC
power lead before installing
the sound bar or changing the
position.
To mount the sound bar on the
wall.
Driving screws
1/8" (3.2 mm)
3/8" (9 mm)
Min. 7/8" (22 mm)
3/16"
(5 mm)
To Next Page
