LC-32A28L, LC-42A48L
16
Fig.7 Fig.8
2. Remove the 5 screws and disconnect 1 cable. Detach the Power board as Fig.9.
Fig.9
3. Remove the 4 screws. Detach the Speakers as Fig.10.
Fig.10
Step 4. Remove the Bracket and Bezel.
1. Remove the 9 screws. Detach the Bracket as Fig.11.
Fig.11
2. Remove the 2 screws and disconnect 1 cable. Detach the Bezel as Fig.12 and Fig.13.
