2008-03-14
LC-32A28L, LC-42A48L
59
[3] 32” WIRING DIAGRAM(LC_32A28L(CMO))
MAIN BOARD
POWER BOARD
CN110
095G801413X937
095G801840X910
CN602
CN902
CN903
CN701
CN406
