CHAPTER 9. PARTS GUIDE
[1] SPARE PARTS LIST
Model: LC-32A28L(CMO)(E329M2NBGWXPNNS)
Item TPV Code Number SHARP 13NC Description Quantity
21 P34T0385PAA 1T0100 9JR3400000009 NECK 1
22 P01T0006 1 9JR0100000028 SCREW (PH+W6#x15 HI-LO W=13) 4
23 0C1T1730 8128 9JR0100000053 SCREW 3X8 PT 2
30 705TZ93448A 9JR7050000136 BEZEL ASSY 1
40 705TZ93449A 9JR7050000137 REAR ASSY 1
50 705GZ934144 9JR7050000069 STAND ASSY 1
63 0Q1T 930 8 47 CR3 9JR0100000007 SCREW 2
75 0M1G1140 6120 9JR0100000046 screw 4
76 0M1G1730 8106 CR3 9JR0100000048 SCREW M3X8 7
80 705TZ91510A 9JR7050000138 BRACKET_SIDE_IO_ASSY 1
84 0Q1G 130 8120 9JR0100000050 SCREW 42A9930011 1
85 0M1G 330 6 47 CR3 9JR0100000025 SCREW 42-D005390 1
86 0Q1T 930 8 47 CR3 9JR0100000007 SCREW 4
87 P85T0116101 9JR8500000006 SHIELDING_DTV 1
88 N02T6008 1 9JR0200000001 SCREW 2
93 P11T0020101 9JR1100000001 COVER _SERVICE 1
94 0M1G1140 6120 9JR0100000046 screw 6
95 0M1G1730 8106 CR3 9JR0100000048 SCREW M3X8 4
96 0M1T 140 10120 9JR0100000039 SCREW M4X10 4
97 0M1T1740 12 47 CR3 9JR0100000049 SCREW 2
98 0Q1T 930 8 47 CR3 9JR0100000007 SCREW 2
99 0M1G 330 6 47 CR3 9JR0100000025 SCREW 42-D005390 1
102 0Q1T 940 12 47 CR3 9JR0100000008 T4X12 SCREW 3
105 0Q1T 940 16 47 CR3 9JR0100000020 SCREW 12
107 P16G0020 1 9JR1600000002 GASKET 16.5*51*1t 1
108 P16G0022 1 9JR1600000003 GASKET(30x17x20mm) 1
126 Z40G 32084306A 9JR4000000089 RATING LABEL 1
127 P40TA00081328A 9JR4000000004 FAMILY SHEET- SERVICE 1
130 Z40G000184313A 9JR4000000090 CARTON LABEL 1
131 P40TN00084357A 9JR4000000022 ITALIAN CAUTION LABEL 1
132 P40TJ00084387A 9JR4000000057 Dolby sentence label 1
135 705TZA4101A 9JR7050000139 DFU ASSY(latam) 1
450 Z44GJ013001 9JR4400000060 CARTON 1
451 Z44GJ016101 9JR4400000055 CUSHION_TL 1
452 Z44GJ016201 9JR4400000056 CUSHION_TR 1
453 Z44GJ016301 9JR4400000057 CUSHION_BL 1
454 Z44GJ016401 9JR4400000058 CUSHION_BR 1
455 P45T 46024 9JR4500000006 PE BAG(950X735x0.72mm) 1
503 P40TD000813 9A 9JR4000000005 family sheet 1
506 P40TD00081311A 9JR4000000006 FAMILY SHEET 1
1050 750TVM315B5211N0SP 9JR7500000026 PANEL V315B5-L02 TW CMO 1
1052 ADTVA2415SA1 9JR9900000055 POWER PCB ASSY 1
1053 KEPF9AB7 9JR9900000056 KEY PCB ASSY 1
1054 IRPF9PB3 9JR9900000035 IR PCB ASSY 1
1172 089G214A21NLSS 9JR8900000014 SHARP-ASSIGN AC POWER CORD 2100mm 1
1176 098TR7BD1NESHD 9JR9800000001 REMOTE CONTROL GA695WJSA 1
1185 078G0050 3 M 9JR7800000015 SPEAKER 8 OHM 5W 800/400mm 135X41mm 1
8391 095G801413X937 9JR9500000081 HARNESS 13P-5P+3P 830mm S-LCDXXTF9764 1
8750 095G801840X910 9JR9500000082 HARNESS 30P-40P 510mm S-LVDSXTF9759 1
0M1G1730 6120 GP 9JR0100000047 M3*6 SCREW 4
705TZA3418A 9JR7050000156 KEY PAD ASSY 1
1051 CBPFA4DSA1 9JR9900000054 MAIN PCB ASSY 1
C101 067G215C101 4H 9JR6700000210
CAP 105℃ 100UF M 25V
1
C102 065G060310432K A 9JR6500000398 CAP CHIP 0603 100nF K 50V X7R 1
C104 067G215C101 4H 9JR6700000210
CAP 105℃ 100UF M 25V
1
C107 065G060310522K T 9JR6500000399 CAP CHIP 0603 1UF K 25V X7R 1
C108 065G060310522K T 9JR6500000399 CAP CHIP 0603 1UF K 25V X7R 1
C109 065G060310522K T 9JR6500000399 CAP CHIP 0603 1UF K 25V X7R 1
C110 067G215C101 4H 9JR6700000210
CAP 105℃ 100UF M 25V
1
