LC-32A28L, LC-42A48L
7
Preparation
Attaching/Detaching the Stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from
Being damaged.
CAUTION:
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
1. Put the TV face down on a safe surface
that is covered by a soft and smooth cloth.
2. Adjust the TV stand to the bottom of the TV.
3. Fasten the screws by using a cross-head screwdriver. (Not supplied).
CAUTION:
• Do not push to hard or put excessive pressure to the stand neck to avoid the damages when you turn the TV for the most comfortable viewing
angle.
NOTE:
To detach the TV stand, perform the steps in reverse order.
Detaching the stand neck for wall mounting
CAUTION:
• Please use care when disassembling cabinet, stand, and pillar for wall mounting.
• Detach the stand neck in the correct direction.
• Do not remove the stand neck from the TV unless using an optional wall mount bracket to mount it.
1. Loosen the 4 screws that secure the stand neck by using a cross-head screwdriver. Remove
stand cover from the TV set.
NOTE:
• To attach the stand neck, perform the steps in reverse order.
• There are 2 types of screws for the stand cover (Machine screws on top and self-tapping screws
at the bottom).
Quick Installation Tips
1. Attach your antenna to the back of the television.
2. Connect the AC plug for the television into the AC outlet.
• Place the TV close to the AC outlet, and keep the power plug within reach.
NOTE:
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE AC CORD CONNECTED.
3. Bundle the cords properly with the cable tie.
