TROUBLESHOOTING GUIDE

THE SCREEN HAS A VERTICAL

LINE OR A HORIZONTAL LINE.

Change V2301.

No

Yes

Chan

g

e IC803.

Is there a normal

waveform at pins 184,

187 and 190 of IC803?

E-7
