ELECTRIC REPLACEMENT PARTS LIST
NR2412 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2413 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2414 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2415 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2416 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2417 9JD110P4000M5 R,NETWORK 4D02WGJ0000TCE
NR2418 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR2419 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR2420 9JD110P4560M5 R,NETWORK 4D02WGJ0560TCE
NR2421 9JD110P4560M5 R,NETWORK 4D02WGJ0560TCE
NR2422 9JD110P4560M5 R,NETWORK 4D02WGJ0560TCE
NR3001 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3002 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3003 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3004 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3005 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3006 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3007 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3008 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3009 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3010 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3011 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
NR3012 9JD110P4470M5 R,NETWORK 4D02WGJ0470TCE
*** OTHERS ***
SH2401 9JD126D000044 TERMINAL PIN YQ-36 or
9JD126R000038 TERMINAL PIN TP00370-21
SH2402 9JD126D000044 TERMINAL PIN YQ-36 or
9JD126R000038 TERMINAL PIN TP00370-21
SH2403 9JD126D000044 TERMINAL PIN YQ-36 or
9JD126R000038 TERMINAL PIN TP00370-21
SH2404 9JD126D000044 TERMINAL PIN YQ-36 or
9JD126R000038 TERMINAL PIN TP00370-21
MAIN PCB ASS'Y
*** PCB ***
PCBF40 9JDA32A01EF40L MAIN PCB ASS'Y CMF111A
*** RESISTORS ***
! R3808 9JDR65584470J R,FUSE 47 OHM 1/4W
*** CAPACITORS ***
C376 9JDE7EYF3102M CE 1000 UF 25V or
9JDE61FF3102D CE 1000 UF 25V
C384 9JDE7EYF3102M CE 1000 UF 25V or
9JDE61FF3102D CE 1000 UF 25V
C3201 9JDE7EYF2222M CE 2200 UF 16V
*** DIODES ***
D101 9JDDE7RB1202B DIODE ZENER UDZS12B TE-177
D102 9JDDE7RB1202B DIODE ZENER UDZS12B TE-177
D103 9JDDE7RB1202B DIODE ZENER UDZS12B TE-177
D104 9JDDE7RB1202B DIODE ZENER UDZS12B TE-177
D105 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D107 9JDDD7R20S300 DIODE SCHOTTKY BARRIER RB520S-30-TE61
D108 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D301 9JDD28R11FS20 DIODE EC11FS2-TE12L
D802 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D803 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D804 9JDDD7R20S300 DIODE SCHOTTKY BARRIER RB520S-30-TE61
D805 9JDDD7R20S300 DIODE SCHOTTKY BARRIER RB520S-30-TE61
D806 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D807 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D808 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D809 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D810 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D811 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D812 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
D813 9JDDE7RB5R62B DIODE ZENER UDZS5.6B TE-17
K2-3
