Sharp LC-32LE600E Service Manual

LC-32/40/46LE600E/RU/S (1st Edition)
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE266F M18 N P KEY Unit
N DUNTKF111F M11 N P MAIN Unit
N DUNTKF308F M02 N P R/C, LED Unit
!
N RUNTKA619W JQZ N P POWER Unit (LC-32LE600E/RU/S)
!
N RUNTKA609W JQZ N P POWER Unit (LC-40LE600E/RU/S)
!
N RUNTKA611W JQZ P POWER Unit (LC-46LE600E/RU/S)
N RUNTK4248T PZB N P LCD Control Unit (LC-32LE600E/RU/S)
N RUNTK4248T PZA N P LCD Control Unit (LC-40LE600E/RU/S)
N RUNTK4248T PZZ N P LCD Control Unit (LC-46LE600E/RU/S)
N RUNTKA595W J01 P LED5-PWB1 Unit
N RUNTKA595W J02 P LED5-PWB2 Unit
N RUNTKA596W J01 P LED6-PWB1 Unit (LC-40/46LE600E/RU/S)
N RUNTKA596W J02 P LED6-PWB2 Unit (LC-40/46LE600E/RU/S)
N RUNTKA598W J01 P LED8-PWB1 Unit (LC-32/46LE600E/RU/S)
N RUNTKA598W J02 P LED8-PWB2 Unit (LC-32/46LE600E/RU/S)
[2] LCD PANEL
N R1LK315D3F ZF0Y N P 32"LCD Panel Module Unit (LC-32LE600E/RU/S)
N R1LK400D3F ZC0Y S P 40"LCD Panel Module Unit (LC-40LE600E/RU/S)
N R1LK460D3F ZN0Y N P 46"LCD Panel Module Unit (LC-46LE600E/RU/S)
[3] DUNTKF111FM11 (MAIN Unit)
C501 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C502 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C503 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C507 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C508 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C510 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C520 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C521 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C522 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C523 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C524 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C525 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C526 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C527 VCKYCZ1HB331KY AA J Capacitor 330p 50V Ceramic
C528 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C529 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C530 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C531 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C532 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C533 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C534 RC-KZA510WJPZY AB J Capacitor
C535 RC-KZA510WJPZY AB J Capacitor
C536 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C537 VCKYCZ1HB471KY AB J Capacitor 470p 50V Ceramic
C538 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C539 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C540 RC-KZA510WJPZY AB J Capacitor
C541 RC-KZA510WJPZY AB J Capacitor
C542 RC-KZA510WJPZY AB J Capacitor
C543 RC-KZA510WJPZY AB J Capacitor
C544 RC-KZA510WJPZY AB J Capacitor
C545 RC-KZA510WJPZY AB J Capacitor
C546 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C547 VCCCCZ1HH560JY AB J
Capacitor 56p 50V Ceramic
C548 VCCCCZ1HH560JY AB J Capacitor 56p 50V Ceramic
C549 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C550 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C551 VCERMZ1CN477MY AE J Capacitor 470 16V (AL)
C552 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C553 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C554 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C555 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C556 VCCCCZ1HH100DY AB J Capacitor 10p 50V Ceramic
C557 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C558 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C559 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C560 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C561 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C562 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C564 RC-KZA616WJQZY AB J Capacitor
C565 VCKYCZ1HB472KY AA J Capacitor 4700p 50V Ceramic
C566 VCKYCZ1HB472KY AA J Capacitor 4700p 50V Ceramic
C567 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
C568 VCEASX1VN226MY AC J Capacitor 22 35V Electrolytic
C569 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C570 RC-KZA067WJZZY AB J Capacitor
C571 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C572 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C573 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
C575 VCKYCY1AB105KY AB J Capacitor 1 10V Ceramic
C576 RC-KZA067WJZZY AB J Capacitor
C577 RC-KZA616WJQZY AB J Capacitor
C578 VCKYCZ1EF104ZY AA J Capacitor 0.1 25V Ceramic
