LC-32/40/46LE600E/RU/S (1st Edition)
6 – 25
2.21. IC9606 (VHiLV5805M+-1Y)
This IC is a block diagram and description LC-19D1E (S58J9LC19D1ES) please see the service manual.
2.22. IC9603 (VHiMM3141YN-1Y)
2.22.1 Block Diagram
2.22.2 Pin Connections and short description
Pin No. Pin Name I/O Pin Function
1 VDD - Voltage supply pin.
4 NC - No connection
5 Vout O Output pin
- NC - No connection
2 GND - Ground pin
3CEI
ON/OFF control pin
Connect CE pin with VDD pin, when it is not used.
㩷㩷㪚㪜㩷㩷㩷㩷㩷㩷㩷㪭㫆㫌
㩷㩷㩷㪣㩷㩷㩷㩷㩷㩷㩷㩷㪦㪝
㩷㩷㩷㪟㩷㩷㩷㩷㩷㩷㩷㩷㪦
