LC-32/40/46LE600E/RU/S (1st Edition)
1 – 1
LC32LE600E
ServiceManual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item
LCD COLOUR TV (32"),
LC-32LE600E, LC-32LE
600RU, LC-32LE600S
LCD COLOUR TV (40"),
LC-40LE600E, LC-40LE
600RU, LC-40LE600S
LCD COLOUR TV (46"),
LC-46LE600E, LC-46LE
600RU, LC-46LE600S
LCD panel
Advanced Super View &
BLACK TFT LCD (32")
Advanced Super View &
BLACK TFT LCD (40")
Advanced Super View &
BLACK TFT LCD (46")
Resolution 2,073,600 pixels (1,920 x 1,080)
Video Colour System PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV Function
TV-Standard
Analogue CCIR (B/G, I, D/K, L/L')
Digital DVB-T (2K/8K OFDM)
Receiving
Channel
VHF/UHF
E5_E69 ch (Digital), E2_E69 ch, F2_F10 ch, I21_I69 ch, IR A_IR J ch
CATV
Hyper-band, S1_S41 ch
TV-Tuning System
Auto Preset 999 ch (non-Nordic), Auto Preset 9999 ch (Nordic), Auto Label,
Auto Sort
STEREO/BILINGUAL NICAM/A2
Viewing angles 176 ° (H), 176 ° (V)
Audio amplifier 10 W x 2
Speaker (35 mm x 100 mm) x 2
Terminals
Antenna
UHF/VHF 75
Din type (Analogue & Digital)
RS-232C D-Sub 9 pin male connector
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 2 SCART (AV input/monitor output, Y/C input)
EXT 3 COMPONENT IN (Y/P
B
(C
B
)/P
R
(C
R
), RCA pin (AUDIO R/L))
EXT 4 15 pin mini D-sub
HDMI 1 (EXT 5) HDMI
HDMI 2 (EXT 6) HDMI
HDMI 3 (EXT 7) HDMI
EXT 8 RCA pin (AV input)
SERVICE USB
HDMI 2/PC AUDIO (R/L) Ø 3.5 mm jack*
DIGITAL AUDIO OUTPUT Optical Digital audio output
C. I. (Common Interface) EN50221, R206001
OUTPUT
RCA pin (AUDIO R/L)
Headphones Ø 3.5 mm jack (Audio output)
OSD language
Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,
Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese,
Russian, Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian
Power Requirement
AC 220 - 240 V, 50 Hz
Power Consumption (Method IEC62087) 92 W (0.3 W Standby) 132 W (0.3 W Standby) 160 W (0.3 W Standby)
Weight
10.5 kg (Without stand),
12.5 kg (With stand)
12.3 kg (Without stand),
15.4 kg (With stand)
18.5 kg (Without stand),
22.5 kg (With stand)
Operating temperature
Cto+4C
The HDMI 2 and EXT 4 terminals can both use the same audio input terminal.
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
*
