LC-32/40/46LE600E/RU/S (1st Edition)
iii
LIST OF CHANGED PARTS (LC-40LE600E/RU/S)
Ref. No. Description
LC-40LE700E/RU/S
(No. S89B4LC32L700)
LC-40LE600E/RU/S
(No. S89B5LC32L600)
Note
PRINTED WIRING BOARD ASSEMBLIES
KEY Unit DUNTKE266FM18 ← —
MAIN Unit DUNTKE306FM01 DUNTKF111FM11 Changed
R/C, LED Unit DUNTKE308FM02 ← —
ICON Unit DUNTKF314FM02 — Abolish
POWER Unit RUNTKA609WJQZ ← —
LCD Control Unit RUNTK4225TPZE RUNTK4248TPZA Changed
LED5 PWB1 Unit RUNTKA595WJ01 ← —
LED5 PWB2 Unit RUNTKA595WJ02 ← —
LED6 PWB1 Unit RUNTKA596WJ01 ← —
LED6 PWB2 Unit RUNTKA596WJ02 ← —
LCD PANEL
40"LCD Panel Module R1LK400D3FZB0Y R1LK400D3FZC0Y Changed
CABINET AND MECHANICAL PARTS
1 Front Cabinet Ass’y CCABAC372WJ11 CCABAC372WJ12 Changed
1-2 Front Decoration Ass’y CDECQB299WJ11 CDECQB299WJ12 Changed
1-4 Diffusion Sheet PSHEPB007WJKZ — Abolish
2 Rear Cabinet Ass’y CCABBB618WJ11 CCABBB618WJ12 Changed
2-2 Terminal Label HiNDPD390WJSA HiNDPD391WJSA Changed
4 Bottom Cover Ass’y CCOVAD464WJ11 — Abolish
5 Side Terminal Angle Ass’y CANGKC375WJ01 CANGKC375WJ02 Changed
5-1 Side Terminal Label HiNDPD408WJSA HiNDPD470WJSA Changed
18 Connecting Cord Main-Power(LB) QCNW-J917WJQZ QCNW-J904WJQZ Changed
19 Connecting Cord Main-Key(KM) QCNW-J979WJQZ — Abolish
20 Connecting Cord Main-R/C, LED(RA) QCNW-J978WJQZ — Abolish
21 Connecting Cord Main-Power(PL) QCNW-G178WJQZ QCNW-J906WJQZ Changed
22 Connecting Cord Main-LCD Control(LW) QCNW-J902WJQZ QCNW-K029WJQZ Changed
24 Connecting Cord Main-LCD Control(LP) QCNW-J905WJQZ QCNW-J801WJQZ Changed
25 Connecting Cord R/C, LED-ICON(IM) QCNW-J918WJQZ — Abolish
33 POP Label (except for Russia) TLABZC319WJZZ TLABZC322WJZZ Changed
33 POP Label (for Russia) TLABZC320WJZZ TLABZC323WJZZ Changed
35 Screw (for HDMI) XBPS730P06000, x4 XBPS730P06000, x3 Abolish (4→3)
N Bottom Cover — GCOVAD464WJ1A Addition
N Connecting Cord Main-R/C, LED-Key(RA/KM) — QCNW-J900WJQZ Addition
N Wire Holder — LHLDW1033CE00 Addition
N Conductor-10x60 — PSLDMB651WJZZ Addition
LCD PANEL MODULE UNIT
1-3 LCD Control Unit RUNTK4225TPZE RUNTK4248TPZA Changed
1-4 Screw XHPS730P06WS0, x6 XHPS730P06WS0, x4 Abolish (6→4)
1-24 40” LCD Panel Unit R1LK400D3FZB0Y R1LK400D3FZC0Y Changed
1-31 Screw LX-BZA213WJF7, x14 LX-BZA213WJF7, x10 Abolish (14→10)
N Washer Screw — LX-BZA348WJF7 Addition
SUPPLIED ACCESSORIES
X4 Stand Unit CDAi-A600WJ02 CDAi-A586WJ02 Changed
X5 Operation Manual (for Europe except East Europe) TiNS-E281WJZZ TiNS-E285WJZZ Changed
X5 Operation Manual (for Sweden) TiNS-E282WJZZ TiNS-E286WJZZ Changed
X5 Operation Manual (for East Europe) TiNS-E283WJZZ TiNS-E287WJZZ Changed
X5 Operation Manual (for Russia) TiNS-E284WJZZ TiNS-E288WJZZ Changed
SERVICE JIGS (USE FOR SERVICING)
Main+LCD Control-Power(LB) QCNW-K036WJQZ QCNW-K037WJQZ Changed
Main-Key(KM) QCNW-G440WJQZ — Abolish
Main-R/C, LED(RA) QCNW-H184WJQZ — Abolish
Main-R/C, LED-Key(RA/KM) — QCNW-K039WJQZ Addition
R/C, LED-ICON(IM) QCNW-G442WJPZ — Abolish
MAIN Unit
Please refer to a Parts list
