IC4401 VHiMT8295AE-1Q CI_controller This is a control IC for PCMCIA cards. This controls information on IC cards
inserted into the PCMCIA card slot (SC4401) or information on software version
upgrade cards saved on flash memories to transfer the data to CPUs and memo-
ries.
IC2701 VHiYDA148QZ-1Y A-AMP This IC is a digital audio power amplifier. It is mounted by 32QFN small package
with 15W or less stereo. it drives by 10W in 26, and 32 types.
IC9612 VHiTCR5SB33-1Y 1CH-SW-REG
BU3.3V-REG
The TCR5SB33 is CMOS general-purpose single-output voltage regulators with
an on/off control input, featuring low dropout voltage and low quiescent bias cur-
rent. The output current is possible up to 200mA or less. In this model, it generate
BU3.3V.
IC9614 VHiS80928NM-1Y Voltage detector with built-
in delay circuit
This IC is a highly precision voltage detector(2.8V) with built-in delay circuit.
In this model, It used as enable signal of BU3.3V_REG.
IC9605 VHiLV5893M+-1Y 1CH-SW-REG
D3.3V-REG
LV5893M is 1.8A 1ch step down switching regulator.
In this model, it generate D3.3V.
IC9611 VHiTCR5SB25-1Y 1CH-SW-REG
2.5V-REG
The TCR5SB25 is CMOS general-purpose single-output voltage regulators with
an on/off control input, featuring low dropout voltage and low quiescent bias cur-
rent. The output current is possible up to 200mA or less. In this model, it generate
CPU2.5V.
IC9608 VHiLV5893M+-1Y 1CH-SW-REG
D5V-REG
LV5893M is 1.8A 1ch step down switching regulator.
In this model, it generate D5V.
IC9604 VHiLV58072M-1Y 1CH-SW-REG
D1.1V-REG
LV58072M is 3A 1ch step down switching regulator.
In this model, it generate D1.1V.
IC9606 VHiLV5805M+-1Y 1CH-SW-REG
D1.8V-REG
LV5805M is 2A 1ch step down switching regulator.
In this model, it generate D1.8V.
IC9603 VHiMM3141YN-1Y CPU1.25V-REG MM3141 is single-output voltage regulators with an on/off control input.
In this model, it generate CPU1.25V.
IC9610 VHiPQ1LAX95-1Y S9V-REG PQ1LAX95 is the low power loss regulator equipped with the on/off function and
the over current protection function. In this model, it generate S9V.
IC2602
IC9601
IC9613
VHiHC2G66DP-1Y Bilateral Switch This IC is provides a dual analog switch. Each switch has two pins for input or
output and an active HIGH enable input.
[POWER UNIT]
IC7102 TNY274PN BU5V
SW-REG-CTL
for 40”/46”
This IC is IC for the switching regulator with Enhanced Flexibility and Extended
Power Range
In this model, non-reg BU5V power supply is generated.
IC7101 UCC28061 UR13V
P-FACTOR
for 46”
This IC is IC that improves Power-Factor in 13V_Regulator circuit of 46 type
power supply circuit.
The protection functions such as UVLO, Brounout, OVP and AOC are built into in
this IC.
IC7200 NCP1606B UR13V
P-FACTOR
for 40”
This IC is IC that improves Power-Factor in 13V_Regulator circuit of 40 type
power supply circuit.
The protection functions such as UVLO, Brounout, OVP and AOC are built into in
this IC.
IC7104 SSC9502S UR13V
SW-REG-CTL for 40”/46”
This IC is switching power supply IC of a monolithic type.
In this model, non-reg UR13V power supply is generated.
IC7505 FA5573 VLCD
LOW-STANDBY
for 40”/46”
This IC is IC for the low standby power requirement type switching power supply
control.
In this model, backlight LED power supply (VLED=187/209V) is generated.
IC7101 VIPER17 BU5V
SW-REG-CTL
for 32”
This IC is switching power supply IC of the off-line converter type with a PWM
control.
In this model, non-reg BU5V power supply is generated.
IC7001 L6562A UR13V
P-FACTOR
for 32”
This IC is IC that improves Power-Factor in 13V_Regulator circuit of 32 type
power supply circuit.
The protection functions such as UVLO, Brounout, OVP and AOC are built into in
this IC.
IC7002 FA5538 UR13V
SW-REG-CTL for 32”
This IC is switching-power-supply control IC of the current mode system where
power MOSFET drives directly. In this model, UR13V (32 types) is generated.
IC7251 FA5511 VLCD
SW-REG-CTL for 32”
This IC is IC for the PWM type switching power supply control.
In this model, backlight LED power supply (VLED=144V) is generated.
