LC-32/40/46LE600E/RU/S (1st Edition)
6 – 21
71 A4 O PCMCIA address bit 4. CI_A4
69 A5 O PCMCIA address bit 5. CI_A5
66 A6 O PCMCIA address bit 6. CI_A6
64 A7 O PCMCIA address bit 7. CI_A7
46 A8 O PCMCIA address bit 8. CI_A8
44 A9 O PCMCIA address bit 9. CI_A9
37 A10 O PCMCIA address bit 10. CI_A10
41 A11 O PCMCIA address bit 11. CI_A11
62 A12 O PCMCIA address bit 12. CI_A12
48 A13 O PCMCIA address bit 13. CI_A13
50 A14 O PCMCIA address bit 14. CI_A14
59 A15 O PCMCIA address bit 15. TS_CIIN_CLK
57 A16 O PCMCIA address bit 16. TS_CIIN_VAL
45 A17 O PCMCIA address bit 17. TS_CIIN_SYNC
47 A18 O PCMCIA address bit 18. TS_CIIN_D0
49 A19 O PCMCIA address bit 19. TS_CIIN_D1
51 A20 O PCMCIA address bit 20. TS_CIIN_D2
54 A21 O PCMCIA address bit 21. TS_CIIN_D3
56 A22 O PCMCIA address bit 22. TS_CIIN_D4
58 A23 O PCMCIA address bit 23. TS_CIIN_D5
61 A24 O PCMCIA address bit 24. TS_CIIN_D6
63 A25 O PCMCIA address bit 25. TS_CIIN_D7
67 RESET O PCMCIA reset. CI_RESET
35 CE1_ O PCMCIA card enable 1. CI_EN1
36 CE2_ O PCMCIA card enable 2. CI_EN2
23 CD1_ I PCMCIA card detection 1. CI_CARDDET1
88 CD2_ I PCMCIA card detection 2. CI_CARDDET2
38 VS1_ I PCMCIA voltage sense 1. C_VS1
65 VS2_ I PCMCIA voltage sense 2. TS_CIOUT_CLK
79 BVD1 I PCMCIA battery voltage detection 1. TS_CIOUT_SYNC
77 BVD2 I PCMCIA battery voltage detection 2. TS_CIOUT_VAL
72 INPACK_ I PCMCIA input port acknowledge. CI_INP_ACK
70 WAIT_ I PCMCIA wait. CI_WAIT
40 IORD_ O PCMCIA IO read strobe. CI_RD
42 IOWR_ O PCMCIA IO write strobe. CI_WR
74 REG_ O PCMCIA register selection. CI_REG
39 OE_ O PCMCIA output enable. CI_OE
53 WE_ O PCMCIA write enable. CI_WE
55 READY I PCMCIA ready. CI_IREQ
89 WP I PCMCIA write protect. CI_IOSIS16
General Purpose Input and Output (GPIO)
5 VCC33 — I/O power 3.3V D3.3V
33 VCC33 — I/O power 3.3V D3.3V
52 VCC33 — I/O power 3.3V D3.3V
68 VCC33 — I/O power 3.3V D3.3V
97 VCC33 — I/O power 3.3V D3.3V
121 VCC33 — I/O power 3.3V D3.3V
10 GND33 — Ground G
43 GND33 — Ground G
60 GND33 — Ground G
76 GND33 — Ground G
104 GND33 — Ground G
126 GND33 — Ground G
15 VCC18 — Core power 1.8V D1.8V
82 VCC18 — Core power 1.8V D1.8V
22 GND18 — Ground G
90 GND18 — Ground G
108 AVDD33_XTAL — Analog crystal power 3.3V D3.3V
111 AVSS33_XTAL — Analog crystal ground G
112 AVDD18_PLL — Analog PLL power 1.8V D1.8V
113 AVSS18_PLL — Analog PLL ground G
Pin No. Pin Name I/O Pin Function Sheet Name
