Sharp LC-32LE700E User Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
7 – 8
A7,B2,B8
,D2,D8,E
7,F2,F8,H
2,H8
VSSQ - Ground. DQ Ground.
J1 VDDL - DLL Power Supply: +1.8V ± 0.1V.
J7 VSSDL - DLL Ground.
J2 VREF I Reference voltage for inputs for SSTL interface.
Pin No. Pin Name I/O Pin Function

Sharp LC-32LE700E Specifications

General

Display diagonal	32 \
Native aspect ratio	16:9
Native refresh rate	100 Hz
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	Yes
HDMI ports quantity	4
USB 2.0 ports quantity	1

Weight and Dimensions

Depth (without stand)	92 mm
Width (without stand)	767 mm
Height (without stand)	502 mm
Weight (without stand)	13500 g
