LC-46/60LE925E
2 – 3
[2] OPERATION MANUAL (LC-46LE925E)
Attaching the stand unit
•
Before performing work, spread cushioning over the surface on which you will be laying the TV. This will prevent it from being damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
1
Confirm that there are nine screws (four long
screws and five short screws) with the stand
unit.
2
Attach the supporting post for the stand unit
onto the base using the four long screws with
a screwdriver as shown.
Supporting
post
3
Insert the stand into the openings on the
bottom of the TV (hold the stand so it will not
drop from the edge of the base area).
Soft cushion
4
Insert and tighten four short screws into the
four holes on the rear of the TV.
5
Attaching the stand cover.
Slide the stand cover into the two catches on
the stand base.
Insert and tighten a short screw into the hole
on the centre of the stand cover.
NOTE
• To detach the stand unit, perform the steps in reverse order.
• A screwdriver is not supplied with this product.
• The stand base is made of glass. Therefore, be careful not to
drop the stand base or apply pressure to it.
• Do not place heavy objects on the stand base.
CAUTION
The stand is made of tempered glass. Read the following precautionary instructions carefully and use it properly.
• Do not drop or place unnecessary stress on the stand when assembling and attaching or removing it.
• Be sure to not accidentally hit the glass part of the stand with a sharp or hard object, as it may cause the glass to break.
• Using tempered glass with scratches for extended periods may lead to damage occurring. If there are scratches on the tempered
glass, do not attempt to use the stand.
To Next Page
