Sharp LC-60LE822E User Manual

LC-60LE822E/LC-60LE822ERU
6 – 12
7) Main Unit Operation [PANEL BUTTON]
8) Menu operation [MENU BUTTON]
9) AV position fixed [AV POSITION FIXED]
Option “RESPOND” or “NORESPOND” (loop enabled)
Default “RESPOND”
Function • RESPOND : The main unit’s keys are enabled.
• NO RESPOND : The main unit’s keys are disabled excluding the POWER key (RECEPTION/STANDBY
key).
Exception • The start operation in the adjustment process mode, inspection mode are enabled regardless of this setting.
• All the keys are enabled regardless of this setting while entering the adjustment process mode, inspection mode
or Public Mode setting screen.
• For the models with the MENU key on the main unit, menu operation is possible regardless of the setting during
the initial setting when the power is turned on for the first time.
Option “RESPOND” or “NO RESPOND” (loop enabled)
Default “RESPOND”
Function The MENU key on the main unit and remote control is decided whether it is enabled or disabled.
Exception • RESPOND : The menu key is enabled.
• NO RESPOND : The menu key is disabled.
: The start operation in the adjustment process mode, inspection mode is enabled regard-
less of this setting.
: All the keys are enabled regardless of this setting while entering the process mode, inspec-
tion mode or Public Mode setting screen.
Disabled key excluding
Menu key when setting to
not default
All the direct transition keys to menu display (AUTO PRESET, MANUAL MEMORY and others)
* These keys does not exist according to the model.
Remarks When setting to “NO RESPOND”
• For the models with the MENU key on the main unit, menu operation is possible regardless of the setting while
the initial setting when the power is turned on for the first time
Option “VARIABLE” or “FIXED” (loop enabled)
Default “VARIABLE”
Function • VARIABLE : AV position is not fixed.
• FIXED : AV position is fixed.
: The image/sound adjustment items in the menu are fixed in the selected state.
: When receiving “AV POSITION” of the remote control, only the actual state is displayed,
and setting is not changed.
Remarks • When receiving the sound select direct keys (AV POSITION key, OPC, DOLBY key, etc.), only the actual state is
displayed; no setting is changed.
* These keys does not exist according to the model.
• The settings for the Public mode are retained after the personal data is initialized, each item for the AV position
and image/sound adjustment are not initialized.

Sharp LC-60LE822E Specifications

General

Power supply type	AC
Power consumption (standby)	0.20 W
Power consumption (typical)	100 W
Child lock	No
Plug and Play	Yes
Audio formats supported	AAC
Video formats supported	H.264, MPEG4
Display diagonal	60 \
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Viewing angle, horizontal	176 °
Internal memory	8000 MB
Audio (L/R) in	0
HDMI ports quantity	4
SCART ports quantity	1
Product color	Black
LED indicators	Stand-by
Panel mounting interface	400 x 400 mm
Remote control type	GA841WJSA
RMS rated power	20 W
Number of speakers	2
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM

Weight and Dimensions

Depth (with stand)	368 mm
Width (with stand)	1439 mm
Height (with stand)	975 mm
Weight (with stand)	51000 g
Depth (without stand)	40 mm
Height (without stand)	913 mm
