Sharp LC-60LE822E User Manual

LC-60LE822E/LC-60LE822ERU
6 – 13
10)OSD display [ON SCREEN DISPLAY]
11)Start mode [INPUT MODE START]
Example of option: “NORMAL”
“TVD (002TV)”, “INPUT1”, “INPUT2”, “INPUT3”, “HDMI1”, “HDMI2”, “HDMI3”, “HDMI4”.
12)Input fixed [INPUT MODE FIXED]
Option “YES”, “NO” or “LIMITED” (loop enabled)
“LIMITED” is looped only in case of need (destination).
Default “YES”
Function • YES : OSD is displayed
• NO : the following OSD is not displayed.
Registration, setting, adjustment menu, channel call, volume bar, and input select
• LIMITED : only a part of OSD (CH call: “New Information” etc. ...) is not displayed.
Key which may be enabled
(Example of the confusing
key)
• It is OK in the case that simple input select occure or the original state returns soon automatically.
Disabled key when setting
to not default
• When setting to “NO”, the keys which is related to visibility of the screen and sound cannot be used.
STILL IMAGE, SCREEN DISPLAY, OFF TIMER, AV POSITION, BRIGHTNESS SENSOR, SCREEN SIZE
SELECT, AUTO PRESET, MANUAL MEMORY, IMAGE SELECT, SOUND SELECT, LANGUAGE, Closed caution
* Disabled keys dependeds on the models.
Remarks • When setting to “NO”,
ON TIMER (Watching reservation) is cleared.
OFF TIMER “SLEEP” is cleared.
* These items does not exist according to the model.
• When setting to “NO”,
These Displays (Version-up, Public mode setting screen, Pass Word input screen of Public Mode,
the adjustment process mode, K mark of inspection mode) are enabled regardless of this setting.
Option “NORMAL” or “Input source 1 (input selection or channel)” . . . (loop enabled)
Default “NORMAL”
Function which kinds of input source or channel is decided when the power turning on.
NORMAL : the content of the last memory is followed.
Remarks • When setting to not Normal,
ON TIMER (Watching reservation) has priority.
• When setting to “NORMAL”, [INPUT MODE FIXED] is set to “VARIABLE”. and [INPUT MODE FIXED] is prohib-
ited to select. (selection impossible.)
Option “VARIABLE” “FIXED”, “ACCTRL” or “AC/RCCTRL” (loop enabled)
Default VARIABLE
Function VARIABLE : If [INPUT MODE START] is set to Normal, input mode is not fixed.
FIXED : when “INPUT MODESTART” is active, it is impossible to switch to another channel or input
source.
AC CTRL : when “INPUT MODESTART” is active the unit starts at the input mode which is selected
when power is turned on in the case of the AC-ON only.
AC/RC CTRL : when “INPUT MODESTART” is active the unit starts at the input mode which is selected
when power is turned on in any case (AC→ON, remote control→ON, main unit's key→ON)
Disabled key when setting
to “FIXED”
CHANNEL (+/-), DIRECT CHANNEL buttons, FLASHBACK, INPUT SELECT, TV/VIDEO, AUTO PRESET, MANUAL
MEMORY, i.LINK, DIRECTINPUTSELECT, ATV, DTV, EPG, RADIO etc. ...
Remarks • If [INPUT MODE START] is Normal, this function cannot be set.
Set to “VARIABLE” automatically.
• When setting to “FIXED”,
The item related to the channel setting and input selection in Menu are not displayed.
ON TIMER (Watching reservation) is not active.
* These items does not exist according to the model.

Sharp LC-60LE822E Specifications

General

Power supply type	AC
Power consumption (standby)	0.20 W
Power consumption (typical)	100 W
Child lock	No
Plug and Play	Yes
Audio formats supported	AAC
Video formats supported	H.264, MPEG4
Display diagonal	60 \
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Viewing angle, horizontal	176 °
Internal memory	8000 MB
Audio (L/R) in	0
HDMI ports quantity	4
SCART ports quantity	1
Product color	Black
LED indicators	Stand-by
Panel mounting interface	400 x 400 mm
Remote control type	GA841WJSA
RMS rated power	20 W
Number of speakers	2
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM

Weight and Dimensions

Depth (with stand)	368 mm
Width (with stand)	1439 mm
Height (with stand)	975 mm
Weight (with stand)	51000 g
Depth (without stand)	40 mm
Height (without stand)	913 mm
