Sharp LC-60LE822E User Manual

LC-60LE822E/LC-60LE822ERU
7 – 9
[External input EXT1] No picture on the display (5)
Does not the picture of the CVBS signal input to EXT1 go out?
Is CVBS signal sent to pin (14) of EXT1 (SC505)? NO Check the setting of an external input device that connects with
EXT1.
YES
Is CVBS signal from EXT1 (SC505) sent to pin (AG29/
SC1_CVBS_Y) of IC3302 (Digital AV decode & Main CPU)?
NO Check the line between SC505 and IC3302.
YES
Refer to “The picture doesn't appear in all modes.”
[External input EXT1] No picture on the display (6)
Does not the picture of the Y/C video signal input to EXT1 go out?
Is Y/C video signal sent to pins (14)/Y and (4)/C of EXT1
(SC505)?
NO Check the setting of an external input device that connects with
EXT1.
YES
Is Y/C signal from EXT1 (SC505) sent to pins (AG29/
SC1_CVBS_Y) and (AG28/SC1_C1) of IC3302 (Digital AV
decode & Main CPU)?
NO Check the line between SC505 and IC3302.
YES
Refer to “The picture doesn’t appear in all modes.”
[External input EXT1] No picture on the display (7)
Does not the picture of the R/G/B signal input to EXT1 go out?
Is RGB1 signal sent to pins (4)/RGB_IN_RED/C, (6)/
RGB_IN_GREEN and (8)/RGB_IN_BLUE of EXT1 (SC505)?
NO Check the setting of an external input device that connects with
EXT1.
YES
Is RGB1 signal from EXT1 (SC505) sent to pins (AH22/RED1),
(AJ22/GREEN_1) and (AJ21/BLUE_1) of IC3302 (Digital AV
decode & Main CPU)?
NO Check the line between SC505 and IC3302.
YES
Refer to “The picture doesn’t appear in all modes.”

Sharp LC-60LE822E Specifications

General

Power supply type	AC
Power consumption (standby)	0.20 W
Power consumption (typical)	100 W
Child lock	No
Plug and Play	Yes
Audio formats supported	AAC
Video formats supported	H.264, MPEG4
Display diagonal	60 \
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Viewing angle, horizontal	176 °
Internal memory	8000 MB
Audio (L/R) in	0
HDMI ports quantity	4
SCART ports quantity	1
Product color	Black
LED indicators	Stand-by
Panel mounting interface	400 x 400 mm
Remote control type	GA841WJSA
RMS rated power	20 W
Number of speakers	2
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM

Weight and Dimensions

Depth (with stand)	368 mm
Width (with stand)	1439 mm
Height (with stand)	975 mm
Weight (with stand)	51000 g
Depth (without stand)	40 mm
Height (without stand)	913 mm
