ORIGINAL SIZES
ORIGINAL SIZES THAT CAN BE TRANSMITTED
The following original sizes can be transmitted
THE SIZE OF THE PLACED ORIGINAL
When a standard size original is placed, the original size is automatically detected and displayed in the base screen as
the "Scan" size.
When the automatic original detection function is operating and the original is a non-standard size, the closest standard
size may be displayed or the original size may not appear. In this event, manually set the correct original size.
☞ Scan mode: SPECIFYING THE SCAN SIZE OF THE ORIGINAL (page 36)
USB memory mode: SPECIFYING THE SCAN SIZE OF THE ORIGINAL (page 55)
Internet fax mode: SPECIFYING THE SCAN SIZE OF THE ORIGINAL (page 69)
STANDARD SIZES
The standard sizes are set in "Original Size Detector Setting" in the system settings (administrator).
List of original size detector settings
Minimum original size Maximum original size
Using the automatic document feeder
A5: 210 mm (width) x 148 mm (length)
(8-1/2" (width) x 5-1/2" (length))
A5R: 148 mm (width) x 210 mm (length)
(5-1/2" (width) x 8-1/2" (length))
297 mm (width) x 800 mm* (length)
(11-5/8" (width) x 31-1/2"* (length))
*A long original can be transmitted.
(Scanning will take place in Mono 2 at a
resolution of 300X300dpi or less.)
Using the document glass 297 mm (width) x 432 mm (length)
(11-5/8" (width) x 17" (length))
Selections
Detectable original sizes
Document glass
Document feeder tray (automatic document
feeder)
AB-1 A3, A4, A4R, A5, B4, B5, B5R A3, A4, A4R, A5, B4, B5, B5R, 8-1/2" x 11",
8-1/2" x 14", 11" x 17"
AB-2 A3, A4, A4R, A5, B5, B5R, 216 mm x 330 mm A3, A4, A4R, A5, B4, B5, B5R, 8-1/2" x 11",
11" x 17", 216 mm x 330 mm
AB-3 A4, A4R, A5, B4, 8K, 16K, 16KR A3, A4, A4R, A5, B4, 8K, 16K, 16KR, 8-1/2" x 11",
11" x 17", 216 mm x 330 mm
Inch-1 11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2"
11" x 17", 8-1/2" x 14", 8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2", A4, A3
Inch-2 11" x 17", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2"
11" x 17", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2", A4, A3
